OPERATING THE ACU
NBD F:1247000 BW:1000 SIG:301
004.53E 52.22N HDG:090.0 L:10000 Fn
5. NBD, GPS and ship’s heading information are shown.
- NBD (Narrow Band Detection) IF tracking frequency: 1247000 kHz
- Detected Band Width: 1000 kHz
- SIG (Signal Level ): 301 (When NBD mode for tracking signal is chosen)
- W (West)/E (East) Longitude: 4.53º E
- N (North)/S (South) Latitude: 52.22º N
- HDG (Ship’s Heading): 90º
- LNB local oscillator (LO) frequency: 10000 MHz
[PWR] ANT: 26.4V LNB: 13V + 0kHz
ACU: 27.1V [POL] TX:V RX:H
6. Press RIGHT arrow key to display the current operation voltage for antenna, ACU and
LNB. POL indicates the TX polarity (VERTICAL) and RX polarity (HORIZONTAL).
V2-81-CFW ANT. SERIAL 1.00/1.00
VP-T529 ACU SERIAL 1.00
7. Press RIGHT arrow key to display the below information.
- Antenna part number, antenna serial number and PCU rmware version.
- ACU part number, ACU serial number, and ACU rmware version.
Press BACK Key to return to the rst page of the antenna current status.
Tracking & Heading
information
Power status
Antenna & ACU
versions
8.Touch RIGHT arrow key to display the USB FUNCTION*
This menu will be displayed automatically if a USB ash drive is plugged into the USB port
located in the front panel of the ACU.
USB FUNCTION*
• UPGRADE FIRMWARE: upgrade the system by using the rmware les
(les format: *.FWP) from the specied folder in the USB ash drive.
• COPY LOG DATA: Copy the up-to-date log data from the system to the USB ash drive.
Select
USB
functions
[USB FUNCTION] SELECT USB FUNCTION
UPGRADE FIRMWARE
To Next Page
