v80G – Marine Satellite Communication System

Antenna Diagnostic Test

Refer to the diagnosis codes for the test results.

Single diagnostic

test result

Full diagnostic test

Full diagnostic

test result

Diagnosis menu

Antenna menu

Setup mode

SETUP MODE ?

YES NO

1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode.

+ANTENNA +SATELLITE

+SYSTEM +INSTALLATION

2. Press OK key to enter ANTENNA menu.

+BLOCK ZONE +DIAGNOSTIC

3. Press arrow keys to move cursor to DIAGNOSIS menu and press OK key to enter it.

DIAGNOSTIC COMMUNICATION

FULL TEST READY

4. Press UP and DOWN arrow keys to select a full diagnostic test or single diagnostic test

and press OK key to execute the selected diagnostic test.

Menus for DIAGNOSIS are FULL TEST and CODE 101 ~ CODE 116.

DIAGNOSTIC FULL TESTING

FULL TEST

- -

5. A full diagnostic is successfully completed.

DIAGNOSTIC COMMUNICATION

CODE 101 RESULT : PASSED

6. A single diagnostic test is successfully completed.
