Intenza 550 Series Elliptical Handbook: Exploded Drawings And Parts List: Intenza 550ETe2 Elliptical Exploded Drawing And Parts List
7. Exploded Drawings, Parts List And Specifications.
7.1 Intenza 550ETe2 Elliptical Exploded Drawing And Parts List
NO ITEM NO ITEMNO ITEM
Console, w/handle
Cover, console, mount, btm
Post, upright
Cover, upright
Holder, bottle
Bracket, holder, bottle, R
Bracket, holder, bottle, L
Holder, bottle
Cover, upright, top
Cover, upright, front, top
Handlebar, L
Handlebar, R
Decal, bug, handlebar, R
Decal, bug, handlebar, L
Post, upright, L, coated
Post, upright, R, coated
Mount, post, top, coated
Cover, upright, btm, w/cable
Cover, upright, rear, top
Incline Board, w/heatsink
Motor, incline, DC12V
Linkarm
Cover, pivot, linkarm
Coating, cover, ramp, side
Stairarm, R, coated
Coating, cover, ramp, side
Stairarm, L, coated
Cover, pedal
Wheel, w/bearing
Sheet, pedal
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Cover, upright, rear, btm
Cover, upright, rear, top, inj
Cap, stabilizer
Foot, adjustable
Generator, w/bracket
LCB, w/heatsink
Cover, rear, top, injection
Cover, rear, inside, R
Cover, crankarm
Cover, side, bottom, R, inj
Tube, fix, cover
Crankarm, coated
Pulley, input, w/shaft
Ramp
Cover, linkarm
Cross, coated
Cover, stairarm, injection
Block, pivot, stairarm
Bearing
Shaft, ramp
Frame, main, coated
Bracket, battery
Pulley, step—up
Belt, drive
Belt, drive
Cover, side, bottom, L w/clip
Wheel, moving
Bracket, wheel
Cap, wheel
Cover, side, top, L
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Bearing, ball, 6004ZZ
Shaft, pulley, step—up
Cover, side, top, R
Bearing, pillow block
Cover, rear, inside, L
Cable, signal, frame, w/core
Cable, TV
Cable, LCB, frame + core
Cable, HDMI
Adaptor, 12V
Cable, connect, frame, RJ45
Cable, connect, frame
Cable, generator, power input
Cable, hybrid, torque control
61
62
63
64
65
66
67
68
69
70
71
72
73
74
.............................. ....... .......................................... ......... .............. .............. ......... ......... .................................. ....... ......
14
22
26
27
60 59 58 57 42 65 50 55 53 54 51
61 46
40
45 39 38 6362
44
56
33
34
31
32
35
25
52
36
41
43
47
48
49
64
24
37
29
15
16
30
28
21
17
18
20
19
23
11 9 10 2 8 4 7 1 6 5 12 13
69
68
67
66
70
71
72
73
74
3
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19
20 21 22 23 24 25 26 27 28 29
30 31 32 33 34 35 36 37 38 39
40 41 42 43 44 45 46 47 48 49
50 51 52 53 54 55 56 57 58 59
60 61 62 63 64
65 66 67
68
69
