Inter-m Amplifier 300PLUS - Page 11

JK5-6 4438091710
JACK SPEAKON (PCB INSERT TYPE)
JACK SPEAKON 2
C501-504 3609104122-T
CAP MA 0.1UF 100V J SMALL
0.1/100(M) 4
R501-504 3039470575-T
RES MO 47 2W J RADIAL
47 2W 4
SP1 4438190410
BINDING POST(2P)
BINDING POST 1
SP2 4438190420
BINDING POST(2P)
BINDING POST 1
AN4 4355465007
CON ASS'Y 4P JST
WAFHW4P3.96 1
CN1-2 4428595006
LW5267/LWB0640/2.5MM-06P
6P 2
GND2 6505958210
GND TERMINAL
GND PLATE 1
LD4 2300032105
LED LTL-1CHG-021A LITEON
LED GRE 1
LD1 LD3 LD5 LD7 2300030105
LED LTL-1CHE-021A LITEON
LED RED 4
LD6 2300032105
LED LTL-1CHG-021A LITEON
LED GRE 1
LD2 2300032105
LED LTL-1CHG-021A LITEON
LED GRN 1
R505 3009102973
RES CF 1K 1/5W J N
1K 1
R506-507 3009472973
RES CF 4.7K 1/5W J N
4.7K 2
VR3-4 3228070100
VR RK16311E0Z0113B
10Kb 2
OUTPUT B'D (C4008499930)
LED B'D (C4008499940)
