Inter-m Amplifier 300PLUS - Electrical Parts List R-300; MAIN BD (C4008499900); 1 CH AMP BD (C4008499910)

Ref No. Part No. Description Value Qty
D200
2058100988 DIODE BRIDGE PBU 804
804 1
C203 3639474255
CAP TL 474K 250V K
474/250 1
CN10 4355923806
CONNECTOR WAFER 06P(J.ST)
6P 1
CN5 4355923807
CON WAFER 07P JST (3.96)
7P 1
CN7 4355923803
CONNECTOR WAFER 03P(J.ST)
3P 1
D201-202 2058100996
DIODE RECTIFIER LT1N4006(4007)
1N 4006 2
C208 3409210141-T
CAP AF RSG 100UF 25V 6 P
100/25 1
C207 3409247991-T
CAP AF RSG 4.7UF 100V 5 P
4.7/100 1
C211 3409210141-T
CAP AF RSG 100UF 25V 6 P
100/25 1
C210 3409210171-T
CAP AF RSG 100UF 50V 8 P
100/50 1
C201-202
3409510335 CAP LSW 10000UF/63V (JAMICON)
10000/63 2
GND1 6505958210
GND TERMINAL
GND PLATE 1
R201 3009104973
RES CF 100K 1/5W J N
100K 1
R202-205 3009223973
RES CF 22K 1/5W J N
22K 4
R206-207 3009183973
RES CF 18K 1/5W J N
18K 2
R221
3039102575-T RES MO 1K 2W J RADIAL
1K 2W 1
R220 3009223973
RES CF 22K 1/5W J N
22K 1
R208 3009223973
RES CF 22K 1/5W J N
22K 1
R209 3009471973
RES CF 470 1/5W J N
470 1
R212 3009104973
RES CF 100K 1/5W J N
100K 1
R210 3009223973
RES CF 2.2K 1/5W J N
22K 1
R211 3009563973
RES CF 56K 1/5W J N
56K 1
RY1 5528009950
RELAY HR-CR3A23 DC 24VH
RLY DC24V 1
IC201 2118050410
IC TA7317P TOSHIBA
TA7317P 1
CN4 4355923804
CONNECTOR WAFER 04P (J.ST)
WAFHW4P3.96 1
C101L 3509102231-A
CAP CE YB 1000PF 50V K AXIAL
0.001 1
C07L C301L C302L 3509104530-T
CAP CE F 0.1UF 50V Z
0.1/50 3
C03L C04L 3509101231-A
CAP CE B 100PF 50V K AXIAL
100P 2
C104L C106L C160L 3529150311-A
CAP CE SL 15PF 50V J AXIAL
15P 3
C08L 3529100311-A
CAP CE SL 10PF 50V J AXIAL
10P 1
C112L 3529330311-A
CAP CE SL 33PF 50V J AXIAL
33P 1
C05L 3529050311-A
CAP CE SL 5P 50V C AXIAL
5P 1
AN5 4355464911
CON ASS'Y 7P JST
7P 1
L101L 2648099920
COIL INDUCTOR 0.6UH
0.6uH 1
AN11-1 4355465109
CON ASS'Y 3P SHIELD
3P 1
AN2 4355465202
CON ASS'Y 6P SHIELD(3P)
6P 1
D101L D102L D103L 2058304100
DIODE IN4148M
1N4148 11
D104L D106L D107L
D108L D109L D110L
D111L D112L
D113L D114L 2058100110
DIODE RL207 PYUNG CHANG
PS 2010 2
C105L C117L 3409210071-T
CAP AF RSG 10UF 50V 5 P
10/50 2
C118L C119L 3409247991-T
CAP AF RSG 4.7UF 100V 5 P
4.7/100 2
C113L C114L 3409222071-T
CAP AF RSG 22UF 50V 5 P
22/50 2
C115L 3409222141-T
CAP AF RSG 220UF 25V J 8 P
220/25 1
ELECTRICAL PARTS LIST ( R - 300 )
MAIN B'D (C4008499900)
1CH AMP B'D (C4008499910)
