Pin no.
Pin name
Circuit
type
Description
FPT-64P-M03
FPT-64P-M09
31 P11/UO0
H
General-purpose I/O port.
The pin is shared with UART/SIO ch0 data output.
32 P12/UCK0
General-purpose I/O port.
The pin is shared with UART/SIO ch0 clock I/O.
33
P13/TRG0/
ADTG
General-purpose I/O port.
The pin is shared with 16-bit PP G ch0 trigger input (TRG0) and A/D
trigger input (ADTG).
34 P14/PPG0
General-purpose I/O port.
The pin is shared with 16-bit PPG ch0 output.
35 P20/PPG00
H
General-purpose I/O port.
The pins are shared with 8/16-bit PPG ch0 output.
36 P21/PPG01
37 P22/TO00
General-purpose I/O port.
The pins are shared with 8/16-bit compound timer ch0 output.
38 P23/TO01
39 P24/EC0
General-purpose I/O port.
The pin is shared with 8/16-bit compound timer ch0 clock input.
40 P50/SCL0
I
General-purpose I/O port.
The pin is shared with I
2
C ch0 clock I/O.
41 P51/SDA0
General-purpose I/O port.
The pin is shared with I
2
C ch0 data I/O.
42 P52/PPG1
H
General-purpose I/O port.
The pin is shared with 16-bit PPG ch1 output.
43 P53/TRG1
General-purpose I/O port.
The pin is shared with 16-bit PPG ch1 trigger input.
44 P60/PPG10
K
General-purpose I/O port.
The pins are shared with 8/16-bit PPG ch1 output.
45 P61/PPG11
46 P62/TO10
General-purpose I/O port.
The pins are shared with 8/16-bit compound timer ch1 output.
47 P63/TO11
48 P64/EC1
General-purpose I/O port.
The pin is shared with 8/16-bit compound timer ch1 clock input.
49 P65/SCK
General-purpose I/O port.
The pin is shared with LIN-UART clock I/O.
50 P66/SOT
General-purpose I/O port.
The pin is shared with LIN-UART data output.
51 P67/SIN L
General-purpose I/O port.
The pin is shared with LIN-UART data input.
52 P43/AN11
J
General-purpose I/O port.
The pins are shared with A/D analog input.
53 P42/AN10
54 P41/AN09
55 P40/AN08
Pin no.
Pin name
Circuit
type
Description
FPT-64P-M03
FPT-64P-M09
56 P37/AN07
J
General-purpose I/O port.
The pins are shared with A/D analog input.
57 P36/AN06
58 P35/AN05
59 P34/AN04
60 P33/AN03
61 P32/AN02
62 P31/AN01
63 P30/AN00
64 AVss - A/D power supply pin (GND)
