GGPIN ASSIGNMENT
GPIN DESCRIPTION
(Continued)
Pin no.
Pin name
Circuit
type
Description
FPT-64P-M03
FPT-64P-M09
1 AVcc - A/D power supply pin
2 AVR - A/D reference input pin
3PE3/INT13
P
General-purpose I/O port.
The pins are shared with the external interrupt input.
4 PE2/INT12
5PE1/INT11
6PE0/INT10
7P83
O General-purpose I/O port
8P82
9 P81
10 P80
11 P71/TI0
H
General-purpose I/O port.
The pin is shared with 16-bit reload timer ch0 output.
12 P70/TO0
General-purpose I/O port.
The pin is shared with 16-bit reload timer ch0 input.
13 MOD B An operating mode designation pin
14 X0
A Subclock oscillation pin
15 X1
16 Vss - Power supply pin (GND)
17 Vcc - Power supply pin
18 C H Capacitor connection pin
19 PG2/X1A
H/A
Single clock product is general-purpose port.
Dual clock product is main clock oscillation pin (32 kHz).
20 PG1/X0A
21 RST
B’ Reset pin
22 P00/INT00
C
General-purpose I/O port.
The pins are shared with external interrupt input. Large current port.
23 P01/INT01
24 P02/INT02
25 P03/INT03
26 P04/INT04
27 P05/INT05
28 P06/INT06
29 P07/INT07
30 P10/UI0 G
General-purpose I/O port.
The pin is shared with UART/SIO ch0 data input.
(FPT-64P-M03, FPT-64P-M09)
ssVA
0NA/03P0
0
N
A
/
13P1
0
N
A
/
23P2
0NA/
3
3P3
0NA/43P4
0N
A
/5
3P
5
0N
A
/6
3P
6
0N
A
/7
3P
7
0NA/04P8
0NA/14P9
1
N
A
/2
4P
0
1N
A
/3
4P
1
NIS/76P
T
OS
/6
6P
KCS/56P
63 62 61 60 59 58 57 56 55 54 53 52 51 50 49
AVcc
1
48
P64/EC1
AVR
2
47
P63/TO11
PE3/INT13
3
46
P62/TO10
PE2/INT12
4
45
P61/PPG11
P E1/INT11
5
44
P60/PPG10
P E0/INT10
6
43
P53/TRG1
P83
7
42
P52/PPG1
P82
8
41
P51/SDA0
P81
9
40
P50/SCL0
P80
10
39
P24/EC0
P71/TI0
11
38
P23/TO01
P70/TO0
12
37
P22/TO00
MOD
13
36
P21/PPG01
X0
14
35
P20/PPG00
X1
15
34
P14/PPG0
Vss
16
33
P13/TRG0/ADT
G
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
ccV
C
*A
1X/
2GP
*
A
0X/
1
G
P
T
S
R
P00TNI/00
P10TNI/10
P20TNI/20
P30TNI/30
P40TNI/40
P50TNI/50
P6
0T
NI/
6
0
P
7
0TN
I/
7
0
0I
U/
0
1P
0OU
/
11
P
P0K
C
U/
2
1
64
TOP VIEW
* Single clock product is general-purpose port, and dual clock product is subclock oscillation pin.
