C310 3529330311-A CAP CE SL 33PF 50V J AXIAL 33P
C308 C358 C360 3529470311-A CAP CE SL 47PF 50V J AXIAL 47P
COIL1-4 3908609980 EMI FILTER 2200PF 2200P
AN404 4355789717 CON ASS’Y 3P VR ASS’Y3P
AN405 4355789721 CON ASS’Y 3P VR ASS’Y3P
AN101 4355789806 CON ASS’Y 4P INPUT ASS’Y4P
AN201 4355789811 CON ASS’Y 4P INPUT ASS’Y4P
JK302 JK304 4408194310 XLR JACK (M) E503A0150N XLR
JK301 JK303 4438090310 JACK COMBINATION CXLF-06L COMBO
SW301 4618999910 SW SS65010-0203-9H-FN
SLIDE/2POLE
R801-804 3039100575-T RES MO 10 2W JR 10 2W
C805-806 3509103530-T CAP CE F 0.01UF 50V Z 0.01/50
C801-804 3609104120-T CAP MA 0.1UF 100V J 0.1/100(M)
ANN105 ANN205 4428596604 LOCK WAFER LW-1143-04P
WAFHW4P3.96
SP1-2 4438091710 JACK SPEAKON (PCB INSERT TYPE) SPEAKON
SP3 4438190410 BINDING POST(2P) SP-TER2P
SP4 4438190420 BINDING POST(2P) SP-TER2P
Q401-404 2008606104-T TR NPN KTC 3198Y KTC 3198
Q451-454
Q409 Q459 2008606108-T TR NPN KTC2240BL (KTC 3200BL) C2240
D401 D451 2058304100 DIODE IN4148M 1N 4148
D403 D453 2058502150 DIODE ZENER UZ-15BM(1N5245B) UZ 15BM
IC401 2118010332 IC NJM 5532DD JRC NJM 5532DD
LD401 2300050105 LED LTL-307E-041A LITEON R5R
PH401 PH451 2408000101 PHOTO COUPLER NTL5C4 NTL5C4
R401 R451 3009102973 RES CF 1K 1/5W J N 1K
R409-410
R459-460
R402 R452 3009104973 RES CF 100K 1/5W J N 100K
R407 R457
R411 R461 3009152973 RES CF 1.5K 1/5W J N 1.5K
R403 R453 3009222973 RES CF 2.2K 1/5W J N 2.2K
R408 R458 3009273973 RES CF 27K 1/5W J N 27K
R404 R421-422 3009472973 RES CF 4.7K 1/5W J N 4.7K
R454
VR401 VR451 3228070100 VR RK16311E0Z0113B (21DETENT) 10KB
C403 C405 C453 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50
C455
C401-402 3409247971-T CAP AF RSG 4.7UF 50V 5 P 4.7/50
C451-452
C404 C454 3609104120-T CAP MA 0.1UF 100V J 0.1/100(M)
AN458 4355466703 WIRE ASS’Y 5P 100MM ASS’Y5P
AN408 4355467003 WIRE ASS’Y 4P 100MM ASS’Y4P
AN103 AN203 4355801007 CON ASS’Y 6P ASS’Y6P
CN406 CN456 4428595002 LW5267/LWB0640/2.5MM-02P WAFER/2P
CN403-405 4428595003 LW5267/LWB0640/2.5MM-03P WAFER/3P
CN401-402 4428595005 LW5267/LWB0640/2.5MM-05P WAFER/5P
SW401 SW451 4628992410 SW PUSH SPUN19X1M011 (SUA29) LIMIT SW
D404 D454 2058304100 DIODE IN4148M 1N 4148
IC402 2118010232 IC NJM072D JRC TL072
R412 R462 3004100953 RES CF 100 1/5W FN SMA-4000 100
R415 R465 3009105973 RES CF 1M 1/5W J N 1M
R414 R464 3009334973 RES CF 330K 1/5W J N 330K
R413 R463 3009822973 RES CF 8.2K 1/5W J N 8.2K
C407 C457 3409810971-T CAP AF NP 1UF 50V 6 P 1/50
C406 C456 3509151231-A CAP CE B 150PF 50V K AXIAL 150P
C408 C458 3539473531-A CAP CE YF 47000PF 50V Z AXIAL 47000P
H1 4355465700 WIRE ASS Y 1P 50MM ASS Y1P
CN407 CN457 4428595002 LW5267/LWB0640/2.5MM-02P WAFER/2P
CN408 4428595004 LW5267/LWB0640/2.5MM-04P WAFER/4P
CN458 4428595005 LW5267/LWB0640/2.5MM-05P WAFER/5P
LD603 2300050105 LED LTL-307E-041A LITEON R5RE
LD604 2300050105 LED LTL-307E-041A LITEON R5RE
LD601 2300052105 LED LTL-307G-041A LITEON R5GR
LD602 2301053105 LED SLA-114L SHINYOUNG (ORG) R5OR
R601-606 3009392973 RES CF 3.9K 1/5W J N 3.9K
R607-610 3009472973 RES CF 4.7K 1/5W J N 4.7K
AN401 4355824503 CON ASS’Y 5P ASS’Y5P
LD704 2300050105 LED LTL-307E-041A LITEON R5RE
LD703 2300050105 LED LTL-307E-041A LITEON R5RE
LD701 2300052105 LED LTL-307G-041A LITEON R5GR
LD702 2301053105 LED SLA-114L SHINYOUNG (ORG) R5OR
R701-706 3009392973 RES CF 3.9K 1/5W J N 3.9K
R707-710 3009472973 RES CF 4.7K 1/5W J N 4.7K
AN402 4355824503 CON ASS’Y 5P ASS’Y5P
Q106 2008005999 TR PNP 2SA 1546 NEC 2SA 1546
Q103 Q137 2008207100-T TR PNP 2SA 970BL-TPE2 2SA 970BL
Q105 2008400960 TR NPN 2SC 1567A-R MATSUSHITA 2SC 1567A
Q107 2008405999 TR NPN 2SC4001 NEC 2SC 4001
Q127 Q138 2008606108-T TR NPN KTC2240BL (KTC 3200BL) KTC 2240BL
Q131-136(for CM15.5)
2028107118 TR PNP 2SA 1943 TOSHIBA 2SA1943
Q131-136(for CM20.5)
2028107944 TR PNP 2SA 1295 W/ACC 2SA1295
Q102 2028107984 TR PNP 2SA 1306A(Y),KTA1659A(Y 2SA 1659
Q111 2028107995 TR PNP MJE15033 (MOTOROLA) MJE15033
Q121-126(for CM15.5)
2028407122 TR NPN 2SC 5200 TOSHIBA 2SC5200
Q121-126(for CM20.5)
2028407888 TR NPN 2SC 3264 W/ACC 2SC3264
Q101 Q104 2028407990 TR NPN 2SC 3298A(Y),KTC4370A(Y KTC 4370
Q108 2028407995 TR NPN MJE15032(MOTOROLA) MJE15032
Q110 2028611998 FET P-CH 2SJ 78 HITACHI 2SJ 78
Q109 2028811998 FET N-CH 2SK215 HITACHI 2SK 215
D125-126 2058100110 DIODE RL207 PYUNG CHANG RL207
D101 D105-106 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006
D124 D134
D103-104 2058304100 DIODE IN4148M 1N 4148
D107-114
D119-120 D123
D121-122 2058322100 DIODE 1SS145 ROHM 1SS145
D116 D118 2058512190 DIODE ZENER 10V 1W(IN4740A) UZ 10BM/1W
IC101 2118010232 IC NJM072D JRC NJM 072D
IC102 2118050410 IC TA7317P TOSHIBA TA 7317P
TH101 2438007993 POSISTOR PTH 9M04 BE 222TS 2F BE222TS
TH102 2438007995 POSISTOR PTH9M04 BH 471TS 2F BH471TS
L101 2648099940 COIL INDUCTOR 1.2UM 1.2uH
R116-117 R177 3009104973 RES CF 100K 1/5W J N 100K
R179 R184
R102 3009113973 RES CF 11K 1/5W J N 11K
R104 3009121973 RES CF 120 1/5W J N 120
R126 3009122973 RES CF 1.2K 1/5W J N 1.2K
R172-173(for CM15.5)
3009823973 RES CF 82K 1/5W J N 82K
R172-173(for CM20.5)
3009124973 RES CF 120K 1/5W J N 120K
R186-187 3009150973 RES CF 15 1/5W J N 15
R178 3009184973 RES CF 180K 1/5W J N 180K
R106 3009202973 RES CF 2K 1/5W J N 2K
R108 3009222973 RES CF 2.2K 1/5W J N 2.2K
R175-176 R185 3009223973 RES CF 22K 1/5W J N 22K
R107(for CM15.5) 3002470953 RES CF 47K 1/5W F N 47K 1%
R107(for CM20.5) 3009303973 RES CF 30K 1/5W J N 30K
R109(for CM15.5) 3002180953 RES CF 18K 1/5W F N 18K 1%
R109(for CM20.5) 3009303973 RES CF 30K 1/5W J N 30K
R103 3009331973 RES CF 330 1/5W J N 330
R122-123 3009393273 RES CF 39K 1/4W JN 39K 1/4W
R181 3009473973 RES CF 47K 1/5W J N 47K
R101 3009561973 RES CF 560 1/5W J N 560
R118-119 R125 3009562973 RES CF 5.6K 1/5W J N 5.6K
R111-112 3009564973 RES CF 560K 1/5W J N 560K
R180 3009682973 RES CF 6.8K 1/5W J N 6.8K
R182-183 3009822973 RES CF 8.2K 1/5W J N 8.2K
R127-128 3039223475 RES MO 22K 1W R 22K 1W
R174 3039479572-F RES MO 4.7 2W J N 4.7 2W
R140-145 3049478783 RES CE 0.47 5W J T HAN NAE 0.47 5W
R158-163
R121 3079121275 RES ERD-2FCVG 121T 1/4W R FR 120
R124 3079121275 RES ERD-2FCVG 121T 1/4W R FR 120
R105 R110 3079151275 RES ERD-2FCVG 151T 1/4W R FR 150
R129-130
R113 3079331275 RES ERD-2FCVG 331T 1/4W R FR 330
R115 R131-132 3079470275 RES ERD-2FCVG 470T 1/4W R FR 47
R114 3079680275 RES ERD-2FCVG 680T 1/4W R FR 68
R120 R146-151 3089101275 RES NFR 100 1/4W J R PHILKO FR 100
R164-169
Ref No. Part No. ValueDescription Ref No. Part No. ValueDescription
R133 3089150275 RES NFR 15 1/4W J R PHILKO FR 15
R170-171 3089332275 RES NFR 3.3K 1/4W J R PHILKO FR 3.3K
R134-139 3089479275 RES NFR 4.7 1/4W J R PHILKO FR 4.7
R152-157
VR101 3248322220-T RES SEMI RH0638C100222 2.2KB
C103 C105 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25
C101 3409247041-T CAP AF RSG 47UF 25V 5 P 47/25
C122 3409247071-T CAP AF RSG 47UF 50V 6 P 47/50
C106-109 3409247971-T CAP AF RSG 4.7UF 50V 5 P 4.7/50
C123 3409810141-T CAP AF NP 100UF 25V 100/25 NP
C121 3509101231-A CAP CE B 100PF 50V K AXIAL 100P
CR102
CR115-116
CR124-125 3509331231-A CAP CE B 330PF 50V K AXIAL 330P
CR113 3529050311-A CAP CE SL 5P 50V M AXIAL 5P
CR123 3529220311-A CAP CE SL 22PF 50V J AXIAL 22P
CR104 3529330311-A CAP CE SL 33PF 50V J AXIAL 33P
CR110 3529680311-A CAP CE SL 68PF 50V J AXIAL 68P
C118-119 3609273120-T CAP MA 0.027UF 100V J 0.027/100(M)
C111-112 C117 3609472120-T CAP MA 0.0047UF 100V J
0.0047/100(M)
C120
C114 3609473120-T CAP MA 0.047UF 100V 0.047/100(M)
AN406 4355466916 WIRE ASS’Y 2P 360MM ASS Y2P
AN407 4355467116 WIRE ASS’Y 2P-4P 360MM ASS
Y2/4P
CN101 4428595002 LW5267/LWB0640/2.5MM-02P WAFER/2P
CN104 4428595003 LW5267/LWB0640/2.5MM-03P WAFER/3P
CN102 4428595005 LW5267/LWB0640/2.5MM-05P WAFER/5P
CN103 4428595006 LW5267/LWB0640/2.5MM-06P WAFER/6P
CN106-108 4465998210 TERMINAL(250)PCB TAB 250T
RY501 5528007700 RELAY AZ971-1A DC24V (ZETTLER) 31H42
Q501 2008606108-T TR NPN KTC2240BL (KTC 3200BL) KTC 2240BL
Q503 2028406113 TR NPN KTD 2058Y (D880Y) D2058
Q502 2028407990 TR NPN 2SC 3298A(Y),KTC4370A(Y KTC 4370
BD501-502 2058100979 DIODE BRIDGE (KBP01G/KBP153G) KPBP 153
D501-504 2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006
D506-507
BD100 2058100998 DIODE KBPC3504 KBPC 3504
D505 2058502240 DIODE ZENER UZ-24BM(1N5252B) UZ 24BM
IC502 2128610800 IC MC7915 COMMON 7915
IC501 2128610900 IC KA7815 COMMON 7815
PO501-502 2438209800 POWER THERMISTOR DSC-1D-22 DSC1D-22
R503 3009102973 RES CF 1K 1/5W J N 1K
R501 3009122973 RES CF 1.2K 1/5W J N 1.2K
R502 3009822973 RES CF 8.2K 1/5W J N 8.2K
C532 3408210191 CAP RSA 100UF 100V SNAP 13 P 100/100
C514 3408210261 CAP RSG 1000UF 35V SNAP 16 P 1000/35
C526-527 3408247169 CAP AF SG 470UF 35V 470/35
C515 C528-529 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50
C516 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25
C531 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25
C524-525 3409222171-T CAP AF RSG 220UF 50V SG 10 P 220/50
C501-504 3409268209 CAP HC 6800UF 160V 6800/160
C510-513 3509472530-T CAP CE F 0.0047UF 50V Z 0.0047/50
C520-523
C505-506 3619474153 CAP POLY TM 0.47UF 250V 0.47/250
P502-503 4355767807 CON ASS’Y 1P (ORG) AWG14
ASS
’
Y1P(ORG)
P504 4355767906 CON ASS’Y 1P (BLK) AWG14
ASS
’
Y1P(BLK)
P501 4355768107 CON ASS’Y 1P(RED) AWG14
ASS
’
Y1P(RED)
AN403 4355797215 CON ASS’Y 3P ASS’Y3P
AN202 4355824510 CON ASS’Y 5P ASS’Y5P
AN102 4355824515 CON ASS’Y 5P ASS’Y5P
CN501-502 4428595003 LW5267/LWB0640/2.5MM-03P WAFER/3P
CN503 4428595009 LW5267/LWB0640/2.5MM-09P WAFER/9P
INLET1 4448997410 AC INLET 6100.4315 250T SCURTE AC INPUT
CN506-511 4465998210 TERMINAL(250)PCB TAB 250T
P51-53 4465998210 TERMINAL(250)PCB TAB 250T
SW101 4625996611
SW POWER(C1350AT) ARCOLECTRIC
POWER SWITCH
F501-503 5508112237 FUSE 51S 20MM 1A/250V K/U/C/J T1AL
RY503 5528008500 RELAY AZ2100-1A-24DE ZETTLER
T9A S1D 22-24
FAN1-2(for CM15.5)
7308998311 FAN(A9225M24B-FS) FAN1
FAN1-2(for CM20.5)
7308998511 FAN(F1238H24B) FAN1
F102 5568224933 CIRCUIT BREAKER(W58-XC4C12A-25 25A
F101(for CM15.5) 5568224933 CIRCUIT BREAKER(W58-XC4C12A-25 25A
5568224833 CIRCUIT BREAKER W28-XQ1A-15 15A
F101(for CM20.5) 5568225033 CIRCUIT BREAKER W58-XC4C12A-35 35A
5568224433 CIRCUIT BREAKER W28-XQ1A-20A 20A
PT1 2828063800 TRANS POWER 120V M-1500 120V
2828063810 POWER TRANS 220V M-1500 220V
2828063820 TRANS POWER 230V M-1500 230V
2828063840 TRASN POWER 240V M-1500 240V
2828063700 TRANS POWER 120V M-2000 120V
2828063710 TRANS POWER 220V M-2000 220V
2828063720 TRANS POWER 230V M-2000 230V
2828063730 TRASN POWER 240V M-2000 240V
IC301-303 2118010332 IC NJM 5532DD JRC NJM 5532DD
R303-306 3002150953 RES CF 15K 1/5W F N 15K 1%
R353-356
R309 R359 3003300953 RES CF 3K 1/5W FN 3K 1%
R312 R362 3003656953 RES CF 6.56K 1/5W FN 6.56K 1%
R307 R357 R370 3009101973 RES CF 100 1/5W J N 100
R308 R358 3009103973 RES CF 10K 1/5W J N 10K
R318 3009104973 RES CF 100K 1/5W J N 100K
R302 R352 3009105973 RES CF 1M 1/5W J N 1M
R368-369 3009153973 RES CF 15K 1/5W J N 15K
R366-367 3009303973 RES CF 30K 1/5W J N 30K
R316-317 3009563973 RES CF 56K 1/5W J N 56K
R301 R351 3009823973 RES CF 82K 1/5W J N 82K
C307 C357 3409210071-T CAP AF RSG 10UF 50V 5 P 10/50
C301-302 C306 3409210141-T CAP AF RSG 100UF 25V 6 P 100/25
C311 C351-352
C356
C309 3409247071-T CAP AF RSG 47UF 50V 6 P 47/50
C303 C353 3529050311-A CAP CE SL 5P 50V M AXIAL 5P
C320 C370 3529103531-A CAP CE F 10000PF 50V Z 0.01/25
C304-305 3529220311-A CAP CE SL 22PF 50V J AXIAL 22P
C354-355 C359
C308 C358
C310 3529330311-A CAP CE SL 33PF 50V J AXIAL 33P
C360 3529470311-A CAP CE SL 47PF 50V J AXIAL 47P
COIL1-4 3908609980 EMI FILTER 2200PF 2200P
AN404 4355763217 CON ASS’Y 3P VR (RED) ASS’Y3P
AN101 4355767312 CON ASS’Y INPUT 2P (3P) ASS’Y2/3P
AN104 4355772907 CON ASS’Y 3P ASS’Y3P
AN201 4355788616 CON ASS’Y 2P INPUT ASS’Y2P
AN405 4355789721 CON ASS’Y 3P VR ASS’Y3P
JK302 JK304 4408194310 XLR JACK (M) E503A0150N XLR
JK301 JK303 4438090310 JACK COMBINATION CXLF-06L COMBI
SW301 4618999910 SW SS65010-0203-9H-FN
SLIDE/2POLE
R801-804 3039100575-T RES MO 10 2W JR 10 2W
C805-806 3509103530-T CAP CE F 0.01UF 50V Z 0.01/50
C801-804 3609104120-T CAP MA 0.1UF 100V J 0.1/100(M)
SP1-2 4438091710 JACK SPEAKON (PCB INSERT TYPE) SPEAKON
SP3 4438190410 BINDING POST(2P) SP-TER2P
SP4 4438190420 BINDING POST(2P) SP-TER2P
CN514-517 4465998210 TERMINAL(250)PCB TAB 250T
Q401-404 2008606104-T TR NPN KTC 3198Y KTC 3198
Q451-454
D401 D451 2058304100 DIODE IN4148M 1N 4148
D403 D453 2058502150 DIODE ZENER UZ-15BM(1N5245B) UZ 15BM
IC401 2118010332 IC NJM 5532DD JRC NJM 5532DD
LD401 2300050105 LED LTL-307E-041A LITEON R5R
PH401 PH451 2408000101 PHOTO COUPLER NTL5C4 NTL5C4
R401 R451 3009102973 RES CF 1K 1/5W J N 1K
R409-410
R459-460
R402 R452 R407 3009104973 RES CF 100K 1/5W J N 100K
R457
R411 R461 3009152973 RES CF 1.5K 1/5W J N 1.5K
R403 R453 3009222973 RES CF 2.2K 1/5W J N 2.2K
R408 R458 3009273973 RES CF 27K 1/5W J N 27K
R404 R421-422 3009472973 RES CF 4.7K 1/5W J N 4.7K
R454
VR401 VR451 3228070100 VR RK16311E0Z0113B (21DETENT) 10KB
Ref No. Part No. ValueDescription Ref No. Part No. ValueDescription
CM7.5/10.5 OUTPUT B’D (4005187850)
CM7.5/10.5 LED2 B’D (4005187840)
CM15.5/20.5 AMP B’D (4005185800)
CM15.5/20.5 POWER B’D (4005185600)
CM15.5/20.5 INPUT B’D (4005185610)
CM15.5/20.5 OUTPUT B’D (4005185630)
CM15.5/20.5 SWITCH B’D (4005183600)
CM7.5/10.5 SWITCH B’D (4005183500)
CM7.5/10.5 BKT B’D (4005183510)
CM7.5/10.5 LED1 B’D (4005187830)
To Next Page
Loading...
Need help?
General
