Ref No. Part No. Description Value Ref No. Part No. Description Value
R19-20 3009752973 RES,MF,7.5K,1/5W,5%,AX N,TA 7.5K
R87 3009821973 RES,MF,820,1/5W,5%,AX N,TA 820
J4-5 J8 1508400501 JUMP WIRE(0.5/52M/M) JUMPER R44-45 R84 3009822973 RES,MF,8.2K,1/5W,5%,AX N,TA 8.2K
J1-3 J6-7 Open Open R28 3009911973 RES,MF,910,1/5W,5%,AX N,TA 910
Q5-6 Q13 2008206985 TR,SG,NPN,800MA,45V,BC337,TO-9 BC337 VR1 3228066400 VR,XVB12111NPJ,25F,15C10K 10KC
Q1-2 2008206995-T TR PNP 2SB 737 ROHM 2SB737 VR2 VR5 VR7 3228066410 VR,XVB12311GPJ,25F,15C100K 100KC*2
Q3-4 Q7-9 Q12 2038100942 TR,SG,PNP,800MA,45V,BC327,TO-9 BC327 VR10 VR12-19 3228066430 VR,XVB12111NPJ,25F,1B20K 20KB
Q14 VR3-4 VR6 VR8 3228066450 VR,XVB12111NPJ,25F,1B20K,C.C,N 20KB CC
Q10-11 Q15-16 2048203010-T TR JFET N SW J112 SILICONIX J112 VR11 3228066460 VR,XVB12311GPJ,25F,1B20K,C.C,N 20KB*2 CC
D1-24 2058304100 DIODE,SW,100MA,75V,1N4148M 1N4148 SVR1 3248510410-T RES SEMI FT-63 TS (100K) 100K
Z1-2 2058500051 DIODE,ZN,500MW,BM,5.1V,DO-35 5.1B C1-2 C9-10 C12 3409210141-T CAP,E,SM,SG,85C,100UF,25V,M,6P 100/25
IC7 2118010132 IC,COMP,NJM2901N,DIP14 2901N C16 C19 C24-25
IC9 IC13 2118010432 IC,OP AMP,NJM2068DD,DIP8 2068DD C36-37 C40-41
IC1 IC3 2118010432 IC,OP AMP,NJM2068DD,DIP8 2068DD C48 C55 C57
IC16 2118010732 IC,OP AMP,NJM5534D,DIP8 5534D C59 C61 C63
IC2 IC4-6 IC8 2118019832 IC,OP AMP,NJM072BDE,DIP8 072BDE C78-79
IC10-12 C104-105
IC14 2128501039 IC 74HC132 74HC132 C8 3409210221-T CAP,E,SM,SG,85C,1000UF,6.3V,M, 1000/6.3
IC15 2128514046 IC,MUX/DEMUX,14053B,DIP16 14053B C49 C52 C69 3409222124-T CAP,E,SM,SG,85C,220UF,10V,M,6. 220/10
IC17 2128611307 IC,VOLT REG,5V,150MA,78L05 7805 C72
LD1-2 LD6-10 2300030107 LED BRIHGT RED BL-C9/JE-5V1E RED C76-77 C80-81 3409222141-T CAP,E,SM,SG,85C,220UF,25V,J,8P 220/25
LD3 LD11 2300031107 LED BRIGHT YEL BL-C9/KC-V1E YEL C45 3409247081-T CAP,E,SM,SG,85C,47UF,63V,M 47/63
LD4-5 2300032107 LED BRIGHT GRN BL-C9/GE-V1E GRN C5 C11 C15 3509101231-A CAP,CE,HI-DI,Y5P,100PF,50V,K,A 100P
R187 3009000973 RES,MF,0,1/5W,5%,AX N,TA 0 C17-18 C22-23
R4-5 R185-186 3009100973 RES,MF,10,1/5W,5%,AX N,TA 10 C38-39 C53-54
R179 R182 3009101973 RES,MF,100,1/5W,5%,AX N,TA 100 C56 C58 C60
R9 R46-47 R90 3009103973 RES,MF,10K,1/5W,5%,AX N,TA 10K C62
R98-101 R114 C74 3509221231-A CAP,CE,HI-DI,Y5P,220PF,50V,K,A 220P
R119 R124-125 C3-4 C20-21 3509331231-A CAP,CE,HI-DI,Y5P,330PF,50V,K,A 330P
R134-149 R154 C6-7 3529100311-A CAP,CE,TEMP,SL,10PF,50V,J,AX,T 10P
R159 R162 C26 C28 C31 3529330311-A CAP,CE,TEMP,SL,33PF,50V,J,AX,T 33P
R165-172 R178 C34 C47 C50-51
R2-3 R10-11 3009104973 RES,MF,100K,1/5W,5%,AX N,TA 100K C70-71 C75
R26-27 R34 R40 C43-44 C67-68 3539103521-A CAP,CE,SEMI,Y5V,0.01UF,50V,Z,A 0.01U
R48-49 R70 R76 C82-103
R92 R106 R113 C106-107
R118 R123 R129 C64-66 3539104531-A CAP,CE,SEMI,Y5V,0.1UF,50V,Z,AX 0.1U
R133 R156-157 C73 3539473531-A CAP,CE,SEMI,Y5V,0.047UF,50V,Z, 0.047U
R163-164 R177 C42 3569105933-T CAP,CE,MONO,1UF,50V,Z,RA,TA 1U
R151 3009105973 RES,MF,1M,1/5W,5%,AX N,TA 1M C33 3609103120-T CAP,FILM,POLYESTR,0.01UF,100V, 0.01/100(M)
R107 R110 R115 3009133973 RES,MF,13K,1/5W,5%,AX N,TA 13K C35 3609123120-T CAP,FILM,POLYESTR,0.012UF,100V 0.012(M)
R120 R126 R130 C27 3609152120-T CAP,FILM,POLYESTR,0.0015UF,100 0.0015(M)
R23 R89 3009151973 RES,MF,150,1/5W,5%,AX N,TA 150 C30 3609222120-T CAP,FILM,POLYESTR,0.0022UF,100 0.0022(M)
R29 3009152973 RES,MF,1.5K,1/5W,5%,AX N,TA 1.5K C32 3609223120-T CAP,FILM,POLYESTR,0.022UF,100V 0.022(M)
R12-13 R153 3009153973 RES,MF,15K,1/5W,5%,AX N,TA 15K C46 3609224122-T CAP,FILM,POLYESTR,SM,0.22UF,10 0.22/100(M)
R15 R18 R42-43 3009182973 RES,MF,1.8K,1/5W,5%,AX N,TA 1.8K C29 3609472120-T CAP,FILM,POLYESTR,0.0047UF,100 0.0047(M)
R78-80 3009184973 RES,MF,180K,1/5W,5%,AX N,TA 180K C13-14 3609683120-T CAP,FILM,POLYESTR,0.068UF,100V 0.068(M)
R83 3009201973 RES,MF,200,1/5W,5%,AX N,TA 200 CN2 4428560750 CON WAF DS1011-50R1GB,AN,50P DS1011-50P
R65 R69 R97 3009202973 RES,MF,2K,1/5W,5%,AX N,TA 2K CN4 4428594903 CON WAFER,BOX(M),3P,AN LA5268-03P
R93 3009203973 RES,MF,20K,1/5W,5%,AX N,TA 20K CN1 4428594912 CON WAFER,BOX(M),12P,AN LW5268-12P
R32 3009222973 RES,MF,2.2K,1/5W,5%,AX N,TA 2.2K CN3 4428595003 CON WAFER,BOX(M),3P,ST LW5267-03P
R52 R180 3009223973 RES CF 22K 1/5W J N 22K S6
4628990110
SW,PUSH,HOR,4PDT,NS,1U,L9.8 PUSH,1U
R7-8 3009242973 RES,MF,2.4K,1/5W,5%,AX N,TA 2.4K S1-5 S7-20
4628990310
SW,PUSH,HOR,DPDT,NS,1U,L9.8 PUSH,1U
R6 R88 R160 3009271973 RES,MF,270,1/5W,5%,AX N,TA 270 BK2 6505961710 BRACKET SW MODEL-1400 BRACKET
R53 R68 R152 3009273973 RES,MF,27K,1/5W,5%,AX N,TA 27K BK1 6505968010 BRACKET PCB PS-A152 BRACKET
R94 3009302973 RES,MF,3K,1/5W,5%,AX N,TA 3K
R81 3009331973 RES,MF,330,1/5W,5%,AX N,TA 330
R35-36 R38-39 3009332973 RES,MF,3.3K,1/5W,5%,AX N,TA 3.3K VR9 3228066300 VR,SLIDE,LCA-1000-A10K,KO-ON 10KA
R66 R71-72 AN3 4369997712 CON ASS'Y 3P FADER 250MM 03P_250mm
R74-75 R86
R102-105 R108
R111 R116 R121
R127 R131
R173-176 R181
R161 3009333973 RES,MF,33K,1/5W,5%,AX N,TA 33K
R33 3009362973 RES,MF,3.6K,1/5W,5%,AX N,TA 3.6K
R54 3009363973 RES,MF,36K,1/5W,5%,AX N,TA 36K
R188-191 3009431973 RES,MF,430,1/5W,5%,AX N,TA open
R85 3009432973 RES,MF,4.3K,1/5W,5%,AX N,TA 4.3K
R91 3009470973 RES,MF,47,1/5W,5%,AX N,TA 47
R16-17 3009471973 RES,MF,470,1/5W,5%,AX N,TA 470
R67 R96 3009472973 RES,MF,4.7K,1/5W,5%,AX N,TA 4.7K
R150 3009473973 RES,MF,47K,1/5W,5%,AX N,TA 47K
R183-184 3009479973 RES,MF,4.7R,1/5W,5%,AX N,TA 4.7
R1 R24-25 3009512973 RES,MF,5.1K,1/5W,5%,AX N,TA 5.1K
R50-51 R55-64
R109 R112 R117
R122 R128 R132
R14 3009560973 RES,MF,56,1/5W,5%,AX N,TA 56
R158 3009561973 RES,MF,560,1/5W,5%,AX N,TA 560
R30-31 3009562973 RES,MF,5.6K,1/5W,5%,AX N,TA 5.6K
R155 3009681973 RES,MF,680,1/5W,5%,AX N,TA 680
R21-22 3009682973 RES,MF,6.8K,1/5W,5%,AX N,TA 6.8K
R95 3009684973 RES,MF,680K,1/5W,5%,AX N,TA 680K
R37 R41 R73 3009750973 RES,MF,75,1/5W,5%,AX N,TA 75
R77
MONO INPUT (4003473600)
MONO FADER (4003473610)
