P-2000/P-3200 Power Amplifier
Specifications
Rated Output (RMS)
P-3200 P-2000
Stereo 8Ω (per channel) 750W 500W
Stereo 4Ω (per channel) 1200W 750W
Stereo 2Ω (per channel) 1400W 1000W
Bridged Mono 8Ω 2400W 1500W
Bridged Mono 4Ω 2800W 2000W
Frequency Response ( ± 0.5dB) 12Hz-35kHz
Input Sensitivity 1Vrms
T.H.D 0.1%
S/N -100dB
Damping Factor better than 200
Output Circuit
P-3200 3-step high efficiency circuit
P-2000 2-step high efficiency circuit
GENERAL
Power Source AC 110V-240V, 50/60Hz,
Power Consumption
P-3200 1100W
P-2000 800W
Weight
P-3200 25kg/55lb
P-2000 24.5kg/54lb
Dimensions 482(W) x 132(H) x 280(D) mm
19(W) x 5.2(H) x 11(D) in.
Specifications and design subject to change without notice for improvements.
15
