Inter-m PAM- 360A User Manual

Ref No Part No Description Value Qty
BD301-302 2058100979
DIODE BRIDGE (KBP01G/KBP153G)
KPBP 152 2
C205 C305 3539152311-A
CAP CE X 1500PF 16V M AXIAL
0.0015 2
C327-330 C336-339 3509472530-T
CAP CE F 0.0047UF 50V Z
0.0047/50 8
C323 C325 3529104531-A
CAP CE F 100000PF 50V Z
0.1 2
C208 C308 C341 3529103531-A
CAP CE F 10000PF 50V Z
0.01 3
C216-217 C316-317 3509102231-A
CAP CE YB 1000PF 50V K AXIAL
1000P 4
C202 C302 C320 3509101231-A
CAP CE B 100PF 50V K AXIAL
100P 3
C206-207 C306-307 3509220130-T
CAP CE SL 22PF 50V J
22P 4
C204 C304 3509330130-T
CAP CE SL 33PF 50V J
33P 2
D206 D209 D214 D306
D309 D315
D201-205 D207-208
D301-302 D304-305
D307-308
D210-211 D310-311 2058322100
DIODE 1SS145 ROHM
ISS 142 4
D212-213 D312-313 2058100110
DIODE RL207 PYUNG CHANG
RL207 4
C201 C301 3409810971-T
CAP AF NP 1UF 50V 6 P
1/50 NP 2
C209 C309 C318 C321 3409210071-T
CAP AF RSG 10UF 50V 5 P
10/50 5
C334
C218-219 3409810141-T
CAP AF NP 100UF 25V
100/25 NP 2
C203 C220 C303 3409210141-T
CAP AF RSG 100UF 25V 6 P
100/25 3
C324 3409210171-T
CAP AF RSG 100UF 50V 8 P
100/50 1
C335 3408210261
CAP RSG 1000UF 35V SNAP 16 P
1000/35 1
C212-213 C312-313 3409222901-T
CAP SG 2.2UF 160V
2.2/160 4
C319 3409222071-T
CAP AF RSG 22UF 50V 5 P
22/50 1
C332 3409222171-T
CAP AF RSG 220UF 50V SG 10 P
220/50 1
C333 3409247071-T
CAP AF RSG 47UF 50V 6 P
47/50 1
C322 3419547177
CAP E SD 470UF 50V (10P)
470/50 1
C326 3419582266
CAP AF HE 8200UF 35V 105'C
8200/35 1
C210-211 C310-311 3609103120-T
CAP MA 0.01UF 100V
0.01/100(M) 4
C214-215 C314-315 3609104122-T
CAP MA 0.1UF 100V J SMALL
0.1/100(M) 4
IC202 2118050410
IC TA7317P TOSHIBA
TA 7317P 1
IC301 2118010590
IC NJM4558D JRC
4558 1
IC302 2118011905
KIA7815API-U
7815 1
L201 L301 2648099940
COIL INDUCTOR 1.2UH
1.2uH 2
PO301 2438007993
POSISTOR PTFM04BE222Q2N34B0
BE222TS 1
PO302 2438007995
POSISTOR PTFM04BH471Q2N34B0
BE471TS 1
R244-245 R250-251
R344-345 R350-351
R210 R310 3009000973
RES CF 0 1/5W JN
02
R365 3009122973
RES CF 1.2K 1/5W J N
1.2K 1
R201 R301 3009101973
RES CF 100 1/5W J N
100 2
3058828786 RES CE 0.82 5W J T 0.82 5W 8
2058304100 DIODE IN4148M 1N 4148 13
2058100996 DIODE RECTIFIER LT1N4006(4007) 1N 4006 6
Electrical Parts List (PAM-240A/360A)
AMP B'D (4005177600)
