Inter-m PAM- 360A User Manual

ZD704 2058502056 DIODE ZENER UZ-5.6BM(1N5232B) 5.6BM 1
AN4 4355462118 CON ASS'Y 16P 420MM PAM-240A/3 16P 1
AN302 4355801021 CON ASS'Y,FL,6P,5264,BH0640,51 6P 1
CN403 4428595003 CON WAFER A2505WV2-03P 3P 1
TER1 4465997605 TERMINAL,SCREW,5P,10MM,2/ST terminal 1
JACK3-4 4438097310 JACK PHONE 4P jack 2
CR726-727 3539102231-A CAP CE YP 1000PF 50V K AXIAL 1000p 2
C108 3609272120-T CAP MA 0.0027UF 100V J 0.0027(M) 6
C103 C104 C106 3409222071-T CAP AF RSG 22UF 50V 5 P 22/50 18
CR109 3509271231-A CAP CE B 270PF 50V K AXIAL 270p 6
CR106-107 3509121231-A CAP CE B 120PF 50V K AXIAL 120p 12
CR108 3529050311-A CAP CE SL 5P 50V C AXIAL 5p 6
CR110 3529330311-A CAP CE SL 33PF 50V J AXIAL 33P 6
CR103-105 CR102 3539102231-A CAP CE YP 1000PF 50V K AXIAL 1000p 24
CR101 3539103521-A CAP,CE,SEMI,Y5V,0.01UF,50V,Z,A 0.01 1
IC101-102 2168220989 IC NJM 2068L JRC 2068L 6
R124 3009100973 RES CF 10 1/5W J N 10 6
R109 R110 3009221973 RES CF 220 1/5W J N 220 12
R106 R108 3009332973 RES CF 3.3K 1/5W J N 3.3K 12
R121 3009154973 RES CF 150K 1/5W J N 150K 6
R125 3009470973 RES CF 47 1/5W J N 47 6
R120 3009184973 RES CF 180K 1/5W J N 180K 6
R119 R122 3009272973 RES CF 2.7K 1/5W J N 2.7K 2
R111 R114 3009132973 RES CF 1.3K 1/5W J N 1.3K 12
R115 3003220953 RES CF 2.2K 1/5W F N 2.2K 1% 6
R118 3004274953 RES CF 274 1/5W FN 274 1% 6
R101-102 3009682973 RES CF 6.8K 1/5W J N 6.8K 12
R103-104 3009474973 RES CF 470K 1/5W J N 470K 12
R105 R107 3009430973 RES CF 43 1/5W J N 43 12
R117 3009000973 RES CF 0 1/5W JN 0 6
R113 R112 R116 R123 3009103973 RES CF 10K 1/5W J N 10K 24
VR101 3228074810 VR RK09K111020153C 50KC 6
VR102-104 3238089910 VR,ROT,HOR,1U,L22.5,50K,B,CC 50KB 18
IC1 2118010590
IC NJM4558D JRC
4558 1
BD601 2058100103 DIODE,BR,25A,400V,KBPC2504,KBP KBPC 2504W 1
D607-611 2058100996
DIODE RECTIFIER LT1N4006(4007)
1N 4006 5
D601-606 D612-616 2058304100
DIODE IN4148M
1N 4148 11
CR601 3549472407 CAP,CE,AC,Y2/X1,4700PF,250VAC, 0.0047/400V 1
CR604-605 3529560311-A CAP,CE,TEMP,SL,56PF,50V,J,AX,T 56P/50V 2
CR602-603 3619474153
CAP POLY TM 0.47UF 250V
0.47/250 2
C783-784 C789 3409210059-T CAP,E,SM,RG,105C,10UF,50V,M,5X 10/50 3
C782 C785 3409222071-T
CAP AF RSG 22UF 50V 5 P
22/50 2
C601-602 3419022205
CAP AF RSG 22UF 50V 5 P
2200/160 2
Q601-610 2008606108-T
KTC3200-BL-AT
KTC3200BL 10
SPEAKER SELECTOR B'D <4005177710>
INPUT B'D <4005411800>

Inter-m PAM- 360A Specifications

General

Brand	Inter-m
Model	PAM- 360A
Category	Amplifier
Language	English
