ELECTRICAL PARTS LIST (PAM-340A)ELECTRICAL PARTS LIST (PAM-340A)
1 2
Part No. Description Q TY Part No. Description Q TY
2008405990-T TR,SW,NPN,100mA,50V,KRC102M,TO-126,TA 2
2008606102-T TR,SW,PNP,100mA,50V,KRA102M,TO-92M,TA 3
1508400501 JUMPER WIRE,0.5/52M/M 51 2008606108-T TR,SG,NPN,100MA,120V,KTC3200BL,TO-92,TA 10
2648609900 INDUCTOR,BEAD 12 2058100996 DIODE,RE,1A,800V,1N4006,DO-41,TA 1
3003220953 RES,MF,2.2K,1/5W,1%,AX N,TA 6 3039222575-T RES,MF,2.2K,2W,5%,RA R,TA 3
3004274953 RES,MF,274,1/5W,1%,AX N,TA 6 3039330575-T RES,MF,33,2W,5%,RA R,TA 3
3009000973 RES,MF,0,1/5W,5%,AX N,TA 6 3039332575-T RES,MF,3.3K,2W,5%,RA R,TA 3
3009100973 RES,MF,10,1/5W,5%,AX N,TA 6 3039479575-T RES,MF,4.7,2W,5%,RA R,TA 4
3009103973 RES,MF,10K,1/5W,5%,AX N,TA 24 3079220275 RES,FS,MF,22,1/4W,5%,RA R,TA 12
3009132973 RES,MF,1.3K,1/5W,5%,AX N,TA 12 3089101275 RES,FS,MF,100,1/4W,5%,RA R,TA 4
3009154973 RES,MF,150K,1/5W,5%,AX N,TA 6 3089479275 RES,FS,MF,4.7,1/4W,5%,RA R,TA 2
30091849730000R RES,MF,180K,1/5W,5%,AX N,TA 6 3248550120-T RES SEMI FT-63 TP(500) 2
3009221973 RES,MF,220,1/5W,5%,AX N,TA 12 3409210071-T CAP,E,SM,SG,85C,10uF,50V,M,5P,TA 5
3009272973 RES,MF,2.7K,1/5W,5%,AX N,TA 18 3409210141-T CAP,E,SM,SG,85C,100uF,25V,M,6P,TA 3
3009332973 RES,MF,3.3K,1/5W,5%,AX N,TA 12 3409210171-T CAP,E,SM,SG,85C,100uF,50V,M,8P,TA 1
3009430973 RES,MF,43,1/5W,5%,AX N,TA 12 3409222071-T CAP,E,SM,SG,85C,22uF,50V,M,5P,TA 1
3009470973 RES,MF,47,1/5W,5%,AX N,TA 6 3409222171-T CAP,E,SM,SG,85C,220uF,50V,M,10P,TA 1
3009474973 RES,MF,470K,1/5W,5%,AX N,TA 12 3409222901-T CAP,E,SM,SG,85C,2.2uF,160V,M,6.3x11,TA 4
3009682973 RES,MF,6.8K,1/5W,5%,AX N,TA 12 3409247071-T CAP,E,SM,SG,85C,47uF,50V,M,6P,TA 1
3509121231-A00R CAP,CE,HI-DI,Y5P,120pF,50V,K,AX,TA 12 3409810141-T CAP,E,NP,NP,85C,100uF,25V,M,10x12.5,TA 2
3509271231-A CAP,CE,HI-DI,Y5P,270pF,50V,K,AX,TA 6 3409810971-T CAP,E,NP,NP,85C,1uF,50V,M,5x11,TA 2
3529050311-A CAP,CE,TEMP,SL,5pF,50V,C,AX,TA 6 3509101130-T CAP,CE,TEMP,SL,100pF,50V,J,RA,TA 2
3529330311-A CAP,CE,TEMP,SL,33pF,50V,J,AX,TA 6 3509220130-T CAP,CE,TEMP,SL,22pF,50V,J,RA,TA 4
3539102231-A CAP,CE,SEMI,Y5P,1000pF,50V,K,AX,TA 24 3509330130-T CAP,CE,TEMP,SL,33pF,50V,J,RA,TA 2
3539103521-A CAP,CE,SEMI,Y5V,0.01uF,50V,Z,AX,TA 6 3509472530-T CAP,CE,HI-DI,Y5V,4700pF,50V,Z,RA,TA 8
3409210071-T CAP,E,SM,SG,85C,10uF,50V,M,5P,TA 12 3609103120-T CAP,FILM,POLYESTR,0.01UF,100V,J,TA 3
3409222071-T CAP,E,SM,SG,85C,22uF,50V,M,5P,TA 18 3609103120-T CAP,FILM,POLYESTR,0.01UF,100V,J,TA 1
3409247071-T CAP,E,SM,SG,85C,47uF,50V,M,6P,TA 30 3609104122-T CAP,FILM,POLYESTR,SM,0.1uF,100V,J,TA 2
3609272120-T CAP,FILM,POLYESTR,0.0027UF,100V,J,TA 6 4458999110 FUSE CLIP 5*20 6
3238083100 VR,ROT,HOR,1U,L15,50K,B 18 3039222575-T RES,MF,2.2K,2W,5%,RA R,TA 1
3238083200 VR,ROT,HOR,1U,L15,50K,C 6 3039330575-T RES,MF,33,2W,5%,RA R,TA 1
4628992410 SW,PUSH,HOR,DPDT,NS,1U,L18 8 3039332575-T RES,MF,3.3K,2W,5%,RA R,TA 1
2168220989 IC,OP AMP,NJM2068L,SIP8 6 3058828786 RES CE 0.82 5W J T 8
2168220989 IC,OP AMP,NJM2068L,SIP8 6 3419547177 CAP,E,SM,SD,85C,470uF,50V,M,10x20 1
4428592820 CON WAFER,BOX(M),20P,2/AN 6 2008005999 TR,SG,PNP,100mA,250V,2SA1546,TO-126 4
4438193710 JACK,XLR(F),1U,3P,AN 6 2028407123 TR,PW,NPN,15A,230V,2SC5200,TO-3P(L) 4
4428595004 CON WAFER,BOX(M),4P,ST 2
2058100996 DIODE,RE,1A,800V,1N4006,DO-41,TA 3
1508400501 JUMPER WIRE,0.5/52M/M 92 4355933805 WAFER,B5P-VH(LF)(SN),LW(3.96),ROHS 1
2058100110 DIODE,RE,2A,1000V,RL207,DO-15,TA 4 2438007995 THERMIST,PTC,100ohm,90C 1
2058100996 DIODE,RE,1A,800V,1N4006,DO-41,TA 2 4428595003 CON WAFER,BOX(M),3P,ST 3
2058304100 DIODE,SW,100mA,75V,1N4148M,DO-34M,TA 13 2008405999 TR,SG,NPN,100mA,250V,2SC4001,TO-126 4
2058499250 DIODE 1SS244 T-72 (ROHM) 4 2028107119 TR,PW,PNP,15A,230V,2SA1943,TO-3P(L) 4
2058501076 DIODE,ZN,500mW,BM,7.5V,DO-35,TA 1 2438007993 THERMIST,PTC,100ohm,90C 1
2058502056 DIODE,ZN,500mW,BM,5.6V,DO-35,TA 4 4678699411 CNT PLUG 1P 2
3001154953 RES,MF,150K,1/5W,1%,AX N,TA 4 26480999400000R COIL,AIR,1.2UH 2
3002200953 RES,MF,20K,1/5W,1%,AX N,TA 4 2058100979 DIODE,BR,1.5A,100V,KBP153G,KBP 2
30022709530000R RES,MF,27K,1/5W,1%,AX N,TA 3 2118010590 IC,OP AMP,NJM4558D,DIP8 1
3009000973 RES,MF,0,1/5W,5%,AX N,TA 2 3609104122-T CAP,FILM,POLYESTR,SM,0.1uF,100V,J,TA 2
3009101973 RES,MF,100,1/5W,5%,AX N,TA 2 4355747010 CON ASS'Y,SH,5P,BH0640,BH0640,210mm 1
3009102973 RES,MF,1K,1/5W,5%,AX N,TA 1 5528098900 RELAY,SPDT,24V,845N-2A-C 1
3009103973 RES,MF,10K,1/5W,5%,AX N,TA 3 4428595005 CON WAFER,BOX(M),5P,ST 1
3009104973 RES,MF,100K,1/5W,5%,AX N,TA 1 3419582266 CAP,E,LA,HE,105C,8200UF,35V,M 1
3009122973 RES,MF,1.2K,1/5W,5%,AX N,TA 1 3408210261 CAP,E,SM,SG,85C,1000uF,35V,M,16P 1
3009153973 RES,MF,15K,1/5W,5%,AX N,TA 4 4353982811 CON ASS'Y,DS,1P,R4.3,P1.8,230mm 1
3009163973 RES,MF,16K,1/5W,5%,AX N,TA 4 4428595006 CON WAFER,BOX(M),6P,ST 1
3009204973 RES,MF,200K,1/5W,5%,AX N,TA 2 1605996010 COOL SHEET MICA TO-3PL(22*27) 8
3009221973 RES,MF,220,1/5W,5%,AX N,TA 2 2028110941 TR,PW,PNP,1A,230V,2SA1837,TO-220IS 2
3009222973 RES,MF,2.2K,1/5W,5%,AX N,TA 2 2028410884 TR,PW,NPN,1A,230V,2SC4793,TO-220IS 5
3009223973 RES CF 22K 1/5W J N 8 2118011905 IC,VOLT REG,15V,7815,TO-220IS 1
3009271973 RES,MF,270,1/5W,5%,AX N,TA 2 6505932610 BKT FAN-R PAM-240/360 1
3009331973 RES,MF,330,1/5W,5%,AX N,TA 6 6505932620 BKT FAN-L PAM-240/360 1
3009333973 RES,MF,33K,1/5W,5%,AX N,TA 4 6705998410 SPACER HOLDER 2
3009334973 RES,MF,330K,1/5W,5%,AX N,TA 1 6705998510 SPACER PS-A152 2
3009473973 RES,MF,47K,1/5W,5%,AX N,TA 16 7308996910 FAN,DC,80X25,BALL,24V,0.21A,40DBA 1
3009561973 RES,MF,560,1/5W,5%,AX N,TA 8 7502089210 HEAT SINK PAM-240A/360A 1
3009563973 RES,MF,56K,1/5W,5%,AX N,TA 2 8009140103R SCREW BM 4X10B
3009681973 RES,MF,680,1/5W,5%,AX N,TA 2 8095997110R ASS'Y SCREW PM 3*22B
3009822973 RES,MF,8.2K,1/5W,5%,AX N,TA 1 8099130121R HEX MSPM 3*12Y
3509101231-A CAP,CE,HI-DI,Y5P,100pF,50V,K,AX,TA 1 8109230083R SCREW #2BTC 3X8B
3539102231-A CAP,CE,SEMI,Y5P,1000pF,50V,K,AX,TA 4 8305999310
3539103521-A CAP,CE,SEMI,Y5V,0.01uF,50V,Z,AX,TA 3
3539104531-A CAP,CE,SEMI,Y5V,0.1uF,50V,Z,AX,TA 2
3539152311-A00R CAP,CE,SEMI,Y5P,1500pF,16V,M,AX,TA 2 1508400501 JUMPER WIRE,0.5/52M/M 103
2008206104-T TR,SG,PNP,100mA,120V,KTA1268BL,TO-92,TA 6 2058100996 DIODE,RE,1A,800V,1N4006,DO-41,TA 3
2008206106-T TR,SG,PNP,100mA,120V,KTA2400GR,TO-92,TA 4 2058304100 DIODE,SW,100mA,75V,1N4148M,DO-34M,TA 8
Part No. Description Q TY Part No. Description Q TY
2058502043 DIODE,ZN,500mW,BM,4.3V,DO-35,TA 1 2128740208 IC CHIME BT8040N 1
2058502056 DIODE,ZN,500mW,BM,5.6V,DO-35,TA 1 3228065900 VR,ROT,HOR,1U,L22.5,50K,B,CC 2
2058502180 DIODE,ZN,500MW,BM,18V,DO-35,TA 1 3228065910 VR,ROT,HOR,1U,BUSH,L22.5,10K,A 7
3009100973 RES,MF,10,1/5W,5%,AX N,TA 5 4355463412 CON ASS'Y 2P 250MM 1
3009102973 RES,MF,1K,1/5W,5%,AX N,TA 4 4355463501 CON ASS'Y 4P 80MM 1
3009103973 RES,MF,10K,1/5W,5%,AX N,TA 11 4355799516 CON ASS'Y,FL,5P,5395,5264,360mm 1
3009104973 RES,MF,100K,1/5W,5%,AX N,TA 8 4355801021 CON ASS'Y,FL,6P,5264,BH0640,510mm 1
3009105973 RES,MF,1M,1/5W,5%,AX N,TA 1 4355801214 CON ASS'Y,FL,4P,5264,BH0640,300MM 1
30091069730000R RES,MF,10M,1/5W,5%,AX N,TA 1 4355933804 CON WAFER,B4P-VH(LF)(SN),JST,ROHS 1
3009123973 RES,MF,12K,1/5W,5%,AX N,TA 2 4355933805 WAFER,B5P-VH(LF)(SN),LW(3.96),ROHS 1
3009133973 RES,MF,13K,1/5W,5%,AX N,TA 1 4355934402 CON ASS'Y,DS,1P,P1.0,P1.0,90mm 1
3009152973 RES,MF,1.5K,1/5W,5%,AX N,TA 1 4428592520 CON WAFER,BOX(M),20P,2/ST 1
3009153973 RES,MF,15K,1/5W,5%,AX N,TA 19 4428595002 CON WAFER,BOX(M),2P,ST 1
3009181973 RES,MF,180,1/5W,5%,AX N,TA 1 4428595003 CON WAFER,BOX(M),3P,ST 2
3009183973 RES,MF,18K,1/5W,5%,AX N,TA 5 4428595004 CON WAFER,BOX(M),4P,ST 1
3009202973 RES,MF,2K,1/5W,5%,AX N,TA 2 4428595005 CON WAFER,BOX(M),5P,ST 2
3009203973 RES,MF,20K,1/5W,5%,AX N,TA 1 4428598304 CON WAFER,LOCK(M),4P,ST 1
3009220973 RES,MF,22,1/5W,5%,AX N,TA 3 4428598313 CON WAFER,LOCK(M),13P,ST 1
3009221973 RES,MF,220,1/5W,5%,AX N,TA 1 4448099970 SOCKET IC 16PIN PC-835 1
3009222973 RES,MF,2.2K,1/5W,5%,AX N,TA 6 5528999601 RELAY,DPDT,24V,1A,125VAC,502N1-2C-S-24V 3
3009223973 RES CF 22K 1/5W J N 4
3009224973 RES CF 220K 1/5W J N 1
3009225973 RES,MF,2.2M,1/5W,5%,AX N,TA 2 2058100996 DIODE,RE,1A,800V,1N4006,DO-41,TA 5
3009274973 RES,MF,270K,1/5W,5%,AX N,TA 1 2058304100 DIODE,SW,100mA,75V,1N4148M,DO-34M,TA 11
3009302973 RES,MF,3K,1/5W,5%,AX N,TA 2 3009100973 RES,MF,10,1/5W,5%,AX N,TA 6
30093039730000R RES,MF,30K,1/5W,5%,AX N,TA 1 3009103973 RES,MF,10K,1/5W,5%,AX N,TA 15
3009330973 RES,MF,33,1/5W,5%,AX N,TA 5 3009332973 RES,MF,3.3K,1/5W,5%,AX N,TA 5
3009332973 RES,MF,3.3K,1/5W,5%,AX N,TA 2 3009473973 RES,MF,47K,1/5W,5%,AX N,TA 10
3009334973 RES,MF,330K,1/5W,5%,AX N,TA 2 3009563973 RES,MF,56K,1/5W,5%,AX N,TA 4
3009393973 RES,MF,39K,1/5W,5%,AX N,TA 4 3529560311-A CAP,CE,TEMP,SL,56pF,50V,J,AX,TA 2
3009472973 RES,MF,4.7K,1/5W,5%,AX N,TA 5 2008606108-T TR,SG,NPN,100MA,120V,KTC3200BL,TO-92,TA 10
3009473973 RES,MF,47K,1/5W,5%,AX N,TA 9 3409222071-T CAP,E,SM,SG,85C,22uF,50V,M,5P,TA 2
3009561973 RES,MF,560,1/5W,5%,AX N,TA 1 3409247044-T CAP,E,SM,RG,105C,47uF,25V,M,5x11,TA 1
3009563973 RES,MF,56K,1/5W,5%,AX N,TA 14 3549472407 CAP,CE,AC,Y2/X1,4700pF,250VAC,M,RA 1
3009683973 RES,MF,68K,1/5W,5%,AX N,TA 1 3630474500 CAP,FILM,M-POLYESTR,0.47UF,250V,K 2
3009752973 RES,MF,7.5K,1/5W,5%,AX N,TA 1 4835002010 CAPACITOR TUBE 1
3509101231-A CAP,CE,HI-DI,Y5P,100pF,50V,K,AX,TA 2 2118010590 IC,OP AMP,NJM4558D,DIP8 1
3509271231-A CAP,CE,HI-DI,Y5P,270pF,50V,K,AX,TA 1 4428595002 CON WAFER,BOX(M),2P,ST 1
3509820231-A00R CAP,CE,HI-DI,Y5P,82pF,50V,K,AX,TA 1 4428595004 CON WAFER,BOX(M),4P,ST 1
3529100311-A CAP,CE,TEMP,SL,10pF,50V,J,AX,TA 1 4235007210
3529300311-A CAP,CE,TEMP,SL,30pF,50V,J,AX,TA 2 4355933801 CON WAFER,B3P-VH(LF)(SN),JST(3.96),ROHS 1
3529470311-A CAP,CE,TEMP,SL,47pF,50V,J,AX,TA 2 4628979810 SW,PUSH,HOR,DPDT,NS,2U,18,28 1
3539104531-A CAP,CE,SEMI,Y5V,0.1uF,50V,Z,AX,TA 2 4628984010 SW,PUSH,HOR,DPDT,NS,1U,BKT,L17.8 1
2008606104-T TR,SG,NPN,150mA,50V,KTC3198Y,TO-92,TA 6 4648098410 SW,POWER,PUSH,HOR,DPST,4A,250V 1
2008606104-T TR,SG,NPN,150mA,50V,KTC3198Y,TO-92,TA 6 4355933803 WAFER,B2P3-VH(LF)(SN),JST,ROHS 1
2008606999-T TR,SG,NPN,150mA,50V,KTC3198BL,TO-92,TA 2 4428596612 CON WAFER,LOCK(M),12P,ST 1
3039479575-T RES,MF,4.7,2W,5%,RA R,TA 3 3419022205 CAP,E,LA,LP,85C,2200uF,160V,M,35x50 2
3039561575-T RES,MF,560,2W,5%,RA R,TA 1 5528098900 RELAY,SPDT,24V,845N-2A-C 5
3248550320-T RES SEMI FT-63 TP(50K) 2 4355857810 CON ASS'Y,DS,2P,5295,5264,200mm 1
3409210059-T00R CAP,E,SM,RG,105C,10uF,50V,M,5x11,TA 3 4355789213 CON ASS'Y,DS,1P,250T08,P2.6,270mm 1
3409210071-T CAP,E,SM,SG,85C,10uF,50V,M,5P,TA 27 4355789313 CON ASS'Y,DS,1P,250T08,P2.6,270mm 2
3409210141-T CAP,E,SM,SG,85C,100uF,25V,M,6P,TA 4 4428595006 CON WAFER,BOX(M),6P,ST 1
3409210971-T CAP,E,SM,SG,85C,1uF,50V,M,5P,TA 6 4355789413 CON ASS'Y,DS,1P,250T08,P2.6,270mm 1
3409222071-T CAP,E,SM,SG,85C,22uF,50V,M,5P,TA 6
3409222171-T CAP,E,SM,SG,85C,220uF,50V,M,10P,TA 2
3409247071-T CAP,E,SM,SG,85C,47uF,50V,M,6P,TA 7 2058502056 DIODE,ZN,500mW,BM,5.6V,DO-35,TA 1
3409247971-T CAP,E,SM,SG,85C,4.7uF,50V,M,5P,TA 6 3009123973 RES,MF,12K,1/5W,5%,AX N,TA 4
3509472530-T CAP,CE,HI-DI,Y5V,4700pF,50V,Z,RA,TA 1 3529560311-A CAP,CE,TEMP,SL,56pF,50V,J,AX,TA 1
3609102120-T CAP,FILM,POLYESTR,0.001UF,100V,J,TA 1 3539102231-A CAP,CE,SEMI,Y5P,1000pF,50V,K,AX,TA 2
3609103120-T CAP,FILM,POLYESTR,0.01UF,100V,J,TA 1 3539102231-A CAP,CE,SEMI,Y5P,1000pF,50V,K,AX,TA 2
3609104122-T CAP,FILM,POLYESTR,SM,0.1uF,100V,J,TA 4 3409222071-T CAP,E,SM,SG,85C,22uF,50V,M,5P,TA 1
3609122120-T CAP,FILM,POLYESTR,0.0012UF,100V,J,TA 2 3409247071-T CAP,E,SM,SG,85C,47uF,50V,M,6P,TA 3
3609333120-T CAP,FILM,POLYESTR,0.033UF,100V,J,TA 2 4458999110 FUSE CLIP 5*20 2
3609472120-T CAP,FILM,POLYESTR,0.0047uF,100V,J,TA 1 3549333001 CAP,FILM,AC,X2,0.033uF,250VAC,M 1
3609822120-T CAP,FILM,POLYESTR,0.0082uF,100V,J,TA 1 4355763617 CON ASS'Y,DS,12P,BH0640,BH0640,390mm 1
3059569786 RES,CE,WW,5.6,5W,5%,RA R 1 4355772907 CON ASS'Y,FL,2P,5264,BH0640,150mm 1
2028406114 TR,PW,NPN,5A,100V,KTD2059,TO-220IS 1 4355801018 CON ASS'Y,FL,6P,5264,BH0640,420mm 1
2128610900 IC,VOLT REG,15V,1A,MC7815CTG,TO-220AB 1 4438097310 JACK,PHONE,1U,4P,AN 2
7505297830 HEAT SINK (TR) PAM-240/360 1 4438192010 JACK,DSUB(F),1U,15P,ST 1
7505299210 HEAT SINK PAM-240A/360A 1 4355747117 CON ASS'Y,SH,4P,5264,BH0640,350MM 1
8099130121R HEX MSPM 3*12Y 1 4465998210 TERMINAL(250)PCB TAB 2
8099130121R HEX MSPM 3*12Y 1 6505968010 BRACKET PCB PS-A152 2
8195000310R HEAT SINK SCREW 1
2028406113 TR,PW,NPN,3A,60V,KTD2058,TO-220AB 1
2118010590 IC,OP AMP,NJM4558D,DIP8 5 2058502056 DIODE,ZN,500mW,BM,5.6V,DO-35,TA 1
2118012032 IC,OP AMP,NJM4560D,DIP8 1 3009182973 RES,MF,1.8K,1/5W,5%,AX N,TA 1
PO WER IN B'D (4005177720)
LINK IN /O UT B'D (4005177730)
