Inter-m POP-120 - Installation of the Speaker; 4 Ohm Speaker Connection

11
ON EARTHING(EARTH GND)
Broadcasting may de heard well without earth connection. But connect the earth to the earth terminal
(GND) for safety and prevention of noise(Fig. 2).
AM
GND
300W
FM75W
ANTENNA
EARTH
(FIGURE 2)
