6
7. AUX INPUT JACK
You can connect the sound source of tuner, deck, CD, videom etc.
8. PRE AMP OUTPUT JACK
You can connect the line out signal of this unit to another amplifier, recorder or signal processor etc.
9. AMP INPUT JACK
You can connect a signal processor like an equalizer or a filter by plugging phone plugs into this jacks.
10. SPEAKER TERMINAL
These terminals are for the connecting the speakers. Select the terminals of 4Ω or high impedance not
to over load.
11. IMPEDANCE SELECTOR SWITCH
This switch is for selecting the impedance of the high impedance terminal on speaker terminal .
*WARNING:For low impedance (4Ω )output remove jumper between opt in &(+)terminals.
For high impedance(25 or 70V) output install the jumper.
DO NOT:Use both at the same time. Doing do could damage your amplifier and vold the warranty.
10
MODEL
Voltage/Impedance
100V
70V
25V
4Ω
333Ω
166Ω 83Ω
163Ω 82Ω
41Ω
21Ω
10.5Ω
5.2Ω
4Ω /11V
4Ω /15.5V
4Ω /21.9V
POP-30
POP-60
POP-120
