MULTI VOICE FILE
12
PV-6232
PV-6232
Communication Method RS-232C
Rated Output (1kHz) 0dB/2kΩ
Frequency Response
AUX IN 80Hz ~ 15kHz
CD IN 80Hz ~ 15kHz
(Output at Rated ±3dB )
MIC IN 150Hz ~ 10kHz
I nput Sensitivity
MIC IN -50dB/47kΩ (BAL)
AUX IN -10dB/47kΩ (UNBAL)
/Impedance
CD IN 0dB/47kΩ (UNBAL, L+R)
Residual Noise (20kHz LPF) -80dB/2kΩ
Head Phone Output(1kHz) -10dB/47kΩ
Operation Temperature -10°C ~ +40°C / 14°F ~ 104°F
Power Source
100–120VAC or 220–240VAC; 50/60Hz
(Supplied AC mains transformer depends on country requirements)
Power Consumption 10W
Weight (SET) 4.3kg/9.5lbs
Dimensions (SET) 482(W)x88(H)x280(D)mm/19(W)x3.5(H)x11(D)in
* Specifications and design are subject to change without notice.
