PROGRAM TIMER
9
PW-6242B
7. REMOTE CONTROL TERMINAL (REMOTE OUTPUT)
- When AC OUTLET is ON, the contact is printed out and when OUTLET is OFF, the contact is not printed
out.
-
It can be used by connecting to contact terminal of external device.
- You can make a remote control of power ON/OFF by connecting to PD-6359A, ECS-6216P.
8. VOICE FILE INPUT TERMINAL (AUDIO IN FROM VOICE FILE)
It is a terminal to connect the audio output terminal of PV-6232A.
9. SERIAL TERMINAL (RS-232C)
It is a terminal to connect with PV-6232A. Also, you can add the scheduling through the management
program by connecting with PC.
10. CHANNEL OUTPUT TERMINAL (CHANNEL OUT)
It is a terminal to print out melody & voice.
11. CHANNEL INPUT TERMINAL (CHANNEL IN)
It is a terminal to take the input of audio signal from the outside. In normal condition, the input signal is
printed out by bypassing to channel output terminal.
PW-6242B_MANUAL_141346_FOR.qxp_RFA 2017. 11. 13. 오후 4:52 페이지 9
