SYSTEM REMOTE MIC STATION/12KEY MIC STATION KEYPAD
5
RM-6024/RM-6012KP
4) The table below shows the set-up method, and if DATA number is added to switch turned ON, it will be
t
he equipment number.
(Ex: When No. 1 and 3 is ON, add 1 and 4 which is actual corresponding number, and then equipment
number will be 5.)
Pin No. 12 3 45
Data 12 4 816
1 ON
2 ON
3 ON ON
4 ON
Address 5 ON ON
15 ON ON ON ON
16 ON
