Inter-m RM-6024 - Front Panel

SYSTEM REMOTE MIC STATION/12KEY MIC STATION KEYPAD
7
RM-6024/RM-6012KP
Front Panel
Front Panel
1. ALL BUTTON
Used when broadcasting to all zones.
2. MIC
Condenser MIC.
3. OUTPUT LEVEL LED
Display the MIC output level.
4. POWER/FAULT/BUSY LED
- POWER LED (GREEN) : displays the power input status.
- FAULT LED (RED) : will be ON if communication error occurs.
- BUSY LED (RED) : will blink if there is any higher priority broadcast.
5 6 7 8 9
1 2 3 4
