Interflex Frodo - 9.Uks,Aken.pdf

Frodo 195
9.
I
38x J
1xDET 10
Place door from inside.
Use waterlevel.
Vertically fix screws in every board.
18x J
2xDET 10a
2xDET 10b
1550
Mark window opening
740
r=499
Cut window opening,
follow the guidelines
II
1xDET 12b
1xDET 12a
8x I
Drill holes Ø3 mm.
before screws.
(FRO 004)
