Interflex Frodo - 13.Leiliuks,Iste.pdf

Frodo 195
13.
I
1xDET 11
Use waterlevel.
10x M
Push door up!
2xDET 11c
Cut on right size
Drill holes Ø4 mm.
before screws.
2xDET 11b
4xDET 11a
Cut on
right size
30x J
2xDET 15a
1xDET 15b
II
380
7x H
1xDET 15
Remove door bottom frame.
4x H
1xDET 30a
1xDET 30b
Floor grates
(FRO 004)
