Chapter 5: Menu reference
190 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
4.2.n.7.3 Shunt limit
The maximum number of system elements that can be shunted at any one time.
4.2.n.8 Schedule
Select schedules for the selected area.
The shortcut menu allows you to assign up to two schedules to each of the
following elements:
• 1 Set
• 2 Shunt
• 3 Prohibit unset
• 4 Chime area
See “Schedule shortcut menu” on page 78 for more information.
4.3 Area groups
Area group menu allows you to assign areas to area groups.
Note: Area group availability depends on the control panel variant. See
“Specifications” on page 35 in Chapter 2 “Installation”.
See also “Area groups” on page 50.
Area group options
4.3.n Select area group
Select an area group to program.
4.3.n.1 AG name
Every area group can be programmed with a name to identify the area.
Use the Area group name screen to enter or edit the area group name. The area
group name can contain up to 16 characters.
