Chapter 5: Menu reference
206 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
• Indala ASC 27 bit
• Indala ASC 26 bit
• Wiegand 32 bit
• C 36 bit
• ATS Wiegand 23 bit
• ATS Wiegand 23 bit
• Mag swipe - Aritech format
• Mag swipe - Midas format
5.1.n.3.5.5 LEDs option
5 LEDs option
>Door locked<
Specifies the status that the reader LEDs indicate (not applicable for PIN
readers).
• Door locked. LED 1 is on when the door is locked.
• Door unlocked. LED 1 is on when the door is unlocked.
• Area set. LED 1 indicates if the area assigned to the door is set. If more than
one area is assigned, all areas assigned to the door must be set before LED
changes state.
• Area unset. LED 1 indicates if the area assigned to the door is unset. If more
than one area is assigned, all areas assigned to the door must be unset
before LED changes state.
• Area set/unset. Readers with dual LED control indicate the area unset and set
with different LED colours.
• Valid/Void. Readers with dual LED control indicate User Valid or Void using
different LED colours.
• LEDs disabled. No LED control.
Note: On readers with dual LED control, LED 2 may also be programmed to
indicate other conditions using door controller macro logic programming. See
“Door controller macro logic” on page 70.
See also “5.1.n.6.3.1 Door areas” on page 199.
5.1.n.3.5.6 Time&Attendance
If set to Yes, the reader function as a time and attendance reader. It causes that
user access events occurring on this reader are sent from the door controller to
the control panel and may be used for user attendance control.
