Chapter 5: Menu reference
134 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
• Searching: Searching for the network to register
• Reg. denied: Registration to the network has been denied
• Unknown: Registration state is unknown
• Roaming: Registered to a network in roaming
1.2.8.4 GPRS net.reg.
4>GPRS net.reg.
Home network
The GPRS network registration state can have the same values as described in
“1.2.8.3 GSM net.reg.” on page 133.
1.2.8.5 GPRS state
5>GPRS net.reg.
Home network
The GPRS network state can be one of the following:
• Not available: GPRS functionality is not available.
• No network: GPRS functionality is available, but no network is present (for
example, SIM card is absent).
• Not established: GPRS functionality is available, but connection is not
established (IP parameters are not assigned).
• Configured: GPRS functionality is available and connection is established.
• Stopped: GPRS functionality is available, but connection is stopped due to
the disconnection time expiration. See “9.3.n.7.8 Disconn.time” on page 280
for more details.
• No data: Unknown error.
1.2.8.6 Network name
Network name is the name of the GSM network that the GSM dialler is currently
registered in. This is read-only information. The name can be “unknown”, if the
network code is not recognized by the communication module.
1.2.8.7 Network code
The network code is the unique identification number of the GSM network in
which the GSM dialler is currently registered.
1.2.8.8 RSSI
The Received Signal Strength Indication (RSSI) value is read-only diagnostic
information.
