Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 133
the “9.1 Central station” menu. See “9.1.n.4.3 Ping host” on page 264 for more
details. See also “1.2.7.n.2 Ping host” on page 132.
1.2.7.n.5 NTP status
The NTP status screen allows you to check the current status of the Network
Time Protocol server configured. Possible server statuses are listed below.
• Inactive: The NTP server is not queried yet. This status is usually present
after panel restart or NTP configuration.
• Unknown: The query was sent, but no answer from NTP server was received
yet.
• Fail: No answer from NTP server.
• OK: NTP server answered the query.
• Link error: Faulty Ethernet line.
1.2.8 GSM diagnostic
The GSM diagnostic menu provides an access to diagnostic tools for GPRS and
SMS connectivity.
1.2.8.1 PIN status
The PIN status is an informational screen that lets you verify the PIN acceptance
status. The status can be one of the following:
• Normal: Accepted by the SIM.
• Unknown: The status is unknown.
• One trial left! The SIM card provides the last attempt for the correct PIN.
• PUK required! The SIM card is locked after three unsuccessful PIN entering
attempts, until the PUK will be provided.
You can only unlock the SIM card by inserting it in a standard cell phone and
providing the PUK. There is no possibility to enter the PUK in the Advisor
Advanced system.
1.2.8.3 GSM net.reg.
3>GSM net.reg.
Home network
The GSM network registration state can be one of the following:
• Inactive: The dialler has not registered in the network, and is not searching
nor connecting
• Home network: Registered in the home network
