Chapter 5: Menu reference
194 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
4.5.n.3 Pics by filter
Additionally to the zones listed in “4.5.n.2 Pics by zone” on page 193, there can
be up to two condition filters that also trigger the camera.
4.5.n.3.m Select filter
Select one of two filters to configure.
4.5.n.3.m.1 Choose filter
00>Not used
01 Internal sire
Choose a filter that activates the selected camera.
4.5.n.3.m.2 Event type <n>
Define a type of the condition filter chosen in “4.5.n.3.m Select filter” above.
The available filter types are listed in “Camera event types” on page 98.
4.5.n.3.m.3 Report as
If the filter has a custom type, it is necessary to assign a reporting event, which
occurs when the filter becomes active.
Notes
• After you leave this menu, the event is shown as a reporting code in SIA
format. See Appendix B “Advisor Advanced reporting codes” on page 327 for
details.
• Only particular reporting events are available.
4.5.n.4 Pics by rep ev
The camera can be also triggered by a selected reporting event.
4.5.n.4.m Select event
1 Rep. event 1
>Not used<
Select one of two reporting events to configure.
