Chapter 5: Menu reference
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual 261
9.1.n.8 Protocol opt
It is possible to customize the communication protocol parameters using the
Protocol opt menu.
9.1.n.8.1 XSIA
The XSIA menu allows you to set options for the SIA and XSIA protocol.
9.1.n.8.1.1 Area modifier
If the Area modifier option is set to Yes, the area modifier is added to the SIA and
XSIA reports. This allows you to send event from multiple areas using the same
account code. See also “9.1.n.5 Accounts” on page 259.
9.1.n.8.1.2 Name chars
The Name chars value defines the length of the name strings used in the XSIA
reporting.
The allowed values are 16 and 30.
9.1.n.8.1.3 Event number
3 Event number
>3 digits<
The Event number value defines the length of the subevent field (user or point).
The allowed values are 2, 3, and 4 digits.
9.1.n.8.1.4 Subev coding
The Subev coding value defines whether the subevent number is reported to the
CS in hexadecimal (hex) or decimal format.
