Chapter 8: Regulations
304 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
Refer to Table 29 below for all supported options for notification requirements.
Table 29: EN 50131-1:2006 options
Notification equipment (Alarm
reporting)
Grade 3 options
A
B
C
D
Remotely powered audible WD
2
Optional
Optional
Optional
Self-powered audible WD
Optional
1
Optional
Optional
Main ATS [1]
ATS 4
ATS 4
ATS 4
ATS 5
Additional ATS [1]
Optional
Optional
ATS 3
Optional
ATS [2]
SP3
SP3
DP3 [3]
SP4
[1] Requirement according to EN 50136:2010
[2] Requirement according to EN 50136:2012
[3] Primary Path — SP4, backup path — SP2
Legend:
• ATS: Alarm transmission system
• SP: Single path alarm transmission system
• DP: Dual path alarm transmission system
The key variations of cards and keys are the following:
Both
• ATS1471 (1 pc.) and ATS1477 (10 pcs.) tags as well as
• ATS1475 (10 pcs.) card badges
have a number of key variations of 67 million minimum.
Both make use of 26 bit (to 48 bit) Hitag protocol.
The installer (user level 3) commissions the system with appropriate additional
functions.
The end-user (user level 2) is able to make use of all these functions.
The Installer can only make use of these functions when he has an access
granted by end-user.
RAS required setting
The keypad/RAS must be mounted within the secure premises, on the entry/exit
route.
Each arming scenario described below meets EN 50131 requirements.
• 2.2.1.n.3.7.1 Card&PIN mode: Card and PIN always
Note: This setting must be applied manually by the installer after the
appropriate cards are defined in the system.
• 2.2.1.n.3.7.3 1 x set/unset: Off
• 2.2.1.n.3.7.4 3 x badge set: Set
• 2.2.1.n.3.11 Quick set: Off
• 4.1.n.6.18 Key unset: Off
