The following chart provides the device numbers that will be reported for trouble conditions.
KEYPAD PARTITION
1 2 3 4 5 6 7 8
1 192 193 194 195 196 197 198 199
2 200 201 202 203 204 205 206 207
3 208 209 210 211 212 213 214 215
4 216 217 218 219 220 221 222 223
5 224 225 226 227 228 229 230 231
6 232 233 234 235 236 237 238 239
7 240 241 242 243 244 245 246 247
8 248 249 250 251 252 253 254 255
NX1192E MAXIMUM WIRE RUN
(Note:
These numbers are for one keypad at the end of the wire. When connecting more
than one keypad to the end of the wire, a heavier gauge wire will be required.)
WHEN CONNECTED TO NX8-E WHEN CONNECTED TO NX-320
Length in feet Wire Gauge Wire Gauge
250' 24 22
500 20 18
1000 18 16
1500 16 14
2500 14 12
SPECIFICATIONS
OPERATING POWER 12 VDC Regulated
Supplied by NX8-E or NX-320
OPERATING TEMPERATURE 32 to 120 degrees F
CURRENT DRAW 110 mA Maximum
75 mA without Sounder
LCD KEYPAD DIMENSIONS 6.4" Wide
5.3" High
1.0" Deep
SHIPPING WEIGHT 2 lbs.
CADDX CONTROLS, INC.
1420 N MAIN STREET; GLADEWATER, TEXAS 75647
TOLL FREE 800-727-2339
FAX 903-845-6811
www.caddx.com
NX1192E INSTALLATION MANUAL
NX1192EIA02 REV. A (04-01-02)
