Interlogix Simon XT Installation Guide

Menu Description
---- Node ID
The Z-Wave node id of the Z-Wave thermostat. If 0, then
the Z-Wave thermostat has not been found. You may
need to troubleshoot the Z-Wave network via the Z-Wave
Setup menu. Press “OK” to have the module try to find
the thermostat again.
---- Mode The Z-Wave thermostat’s current mode (Off, Heat, Cool)
---- Setpoints
The current heating and cooling setpoints of the Z-Wave
thermostat. These are the temperature thresholds that
determine when the heating or cooling unit will turn on.
---- Fan The current fan mode (Auto, On)
---- Schedules
Shows whether the thermostat is running on a schedule
(On), or is using a fixed setpoint. Note that these
thermostat schedules must be set from the Alarm.com
website. Some Z-Wave thermostats allow setting
schedules directly at the thermostat. These built-in
schedules cannot be set or controlled via the website or
via the touch screen (2WTTS).
---- Update 2WTTS
Press OK to force an update of the thermostat
information shown on the touch screen (2WTTS). Note
that these updates may take several minutes to
complete. To speed up the process, go into System
Programming. This puts the panel in high-speed
communication mode with the touch screen.
---- Remove From 2WTTS
To remove the association between the Z- Wave
thermostat and the touch screen (2WTTS). This will hide
the Thermostat page on the 2WTTS.
https://answers.alarm.com/ADC/Partner/Installation_and_Troubleshooting/Panels/Interlogix_Simon_XT/Interlogix_Simon_XT_…
Updated: Tue, 31 Mar 2020 20:51:49 GMT
19

Interlogix Simon XT Specifications

Power

power requirements	6V nominal
standby current	30mA (10mA in PowerSave Mode)
peak current	1.7 A

Operating Environment

operating temperature	32 to 120°F (0 to 49°C)
storage temperature	-30 to 140°F (-34 to 60°C)
max. relative humidity	90% non-condensing

Dimensions

height	4 1/16 in.
width	1 7/8 in.
