Interlogix TruPortal TP-ADD-2D-BRD User Manual

6 TruPortal Dual Door Interface Module Quick Reference
TB4 AUX Aux Input
GND COM/Shared
RTE Request to Exit
TB5 NO1 Normally Open
COM1 Aux Relay
NC2 Normally Closed
COM2 Common
NO2 Normally Open
TB6 +12V (+) 12V - Red
A Data A - Green
B Data B - Yellow
0V (-) 0V - Black
TB8 NO1 Normally Open
COM1 Aux Relay
NC2 Normally Closed
COM2 Common
NO2 Normally Open
TB9 AUX Aux Input
GND COM/Shared
RTE Request to Exit
TB10 DCNT Door Contact Input
GND COM/Shared
RTMP Reader Tamper
BUZ BUZ Out (-)
TB11 5/12 (+) 5/12 VDC
GRN Green LED
RED/RXD Red LED
R1D1 R1 Data 1
R1D0 R1 Data 0
GND (-) 0V Signal Ground
R2D1 R2 Data 1
R2D0 R2 Data 0
Terminal Block Pin Label Description

Interlogix TruPortal TP-ADD-2D-BRD Specifications

General

Brand	Interlogix
Model	TruPortal TP-ADD-2D-BRD
Category	Control Unit
Language	English
