Chapter 1 — Using the Computer
CK3 Mobile Computer User’s Manual 19
When the CK3 successfully reads a bar code label, you hear a high
beep and the green Good Read LED turns on briefly.
4 Release the Scan button or trigger.
Scanning With an Area Imager
Your CK3 may come with one of two types of area imagers:
• Extended range area imager
• Near-far range area imager
Both area imagers are equipped with a laser pointer and framer to
help you aim at bar codes, allow you to scan 2D bar code symbologies,
and support omni-directional (360°) scanning. Omnidirectional
scanning lets you position the CK3 in any orientation to scan a bar
code label.
Scanning With the Extended Range Area Imager
1 Press to turn on the CK3.
2 Point the scanner window at the bar code label, and hold the CK3
steady a few inches from the label.
