EasyLAN 10i2 Ethernet Adapter Quick Start Guide 7
Connectors, LED, and Button Table
Part Description
10BaseT connector Connects the EasyLAN 10i2
adapter to a 10 Mbps Ethernet
network via a 10BaseT cable.
External power supply
connector (external
adapter only)
Connects the external EasyLAN
10i2 adapter to a power source via
a power supply.
Parallel port connector
(external adapter only)
Provides the external EasyLAN
10i2 adapter with a single
high-speed parallel port that can
connect directly, without the need
of cabling, to an Intermec printer
with a parallel port installed.
LED The LED provides information
on power-up diagnostics and
network activity.
Test button Use the Test button to:
• Print a test label that shows
some of the EasyLAN 10i2
adapter’s settings. Printers that
do not use the Intermec
Printer Language (IPL) or
Direct Protocol (DP), such as
the EasyCoder 91, 7422, C4,
or PC4 or the ColorCoder V4,
cannot print a test label.
• Reset the EasyLAN 10i2
adapter’s settings to the factory
default settings.
For more help, see “Printing a
Test Label” on page 10.
