Intermec PF8D User Manual

Appendix B — Default Settings
76 PF8d and PF8t Desktop Printer User’s Guide
Default Configuration
Use this appendix to view the default settings on the printer. If you
need to restore factory defaults at any time, you can use PrintSet or
the printer home page to reset the printer.
To reset the printer to factory defaults using Printset
• Use the Factory Default Wizard in the Printer Tasks box.
To reset the printer to factory defaults using the home page
1 Start a web browser application.
2 In the address field type the IP address of your printer and press
Enter. The printer home page appears.
3 Click Login and enter your administrator name and password.
The Set General Configuration page appears.
4 On the navigation pane, click Configuration. The Configuration
page appears.
5 Click TCP/IP > Reset.
6 Reboot the printer.
The following tables list the default values of the configuration
commands supported on the PF8d and PF8t printers. If you restore
the printer to the factory default settings, these are the values it uses.
Printer Default Settings
Serial Communication Parameters
Parameter Default Value
Baud rate 9600
Data bits 8
Parity None
Stop bits 1
Protocol Xon/Xoff

Intermec PF8D Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
RS-232 ports	1
Standard interfaces	USB 2.0
Connectivity technology	Wired
Flash memory	4 MB
Certification	CE, FCC Class A, cULus, UL, GS, TUVGS, CCC, C-TICK, BSMI
Internal memory	8 MB
Built-in barcodes	MaxiCode, PDF417
Page description languages	EPL
Form factor	Desktop
Dimensions (WxDxH)	168 x 218 x 116 mm
Compatible operating systems	Windows 98/Me/2000/XP Pro/Server 2003/Vista
Core diameter	25.4 mm
Ribbon length	274.32 m
Maximum media length	1727 mm
Maximum roll diameter	127 mm
Supported paper width	104 mm
Maximum media length (imperial)	68 \
Supported paper width (imperial)	4.1 \
Power requirements	100–240 V AC/50–60 Hz, 1.9 A
AC adapter output current	3 A
AC adapter output voltage	24 V
Storage temperature (T-T)	40 - 104 °F
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
