33
Display Type: 128 x 160 pixels; 20,480 total pixel Super Twist LCD
Depth Ranges: 18 overlapping depth ranges, 0 - 20 to 0 - 400 feet
Forward Ranges: 18 overlapping forward ranges, 0 - 30 to 0 - 600 feet
Transmit Frequency: 200 kHz
Zoom Ranges: Variable Zoom allows 25% of depth range to be displayed
across the entire screen.
Pulselength and
Sounding Rates: Automatically optimized for selected range.
Transmitter Power: Over 400 watts RMS (3,200 watts peak to peak)
Power Requirements: 10.5 to 16 VDC, less than 0.5 Amp.
Dimensions: 7.5”W x 5.5”H x 3.5”D
Standard Equipment: Display unit, 12 VDC power cable with in-line fuse, mounting
bracket with knobs, operation manual and depth transducer w/ 30’
cable.
Specifications
12 VDC Power
Supply Cable
Part # 04-0001-008
Scanning only
Thru-Hull Transducer
Part # T1-I200-026
Scanning only
Transom Transducer
Part # T1-I200-025
