To enable the handset to be supported in the cradle when the phone is mounted
on the wall, follow the procedure shown in Figure 3 to reserve the HANDSET
RETAINER.
1. Use screw-driver to push the
HANDSET RETAINER
2. Push the HANDSET RETAINER
out of the slot
4. Insert the HANDSET RETAINER
back into it's slot
3. Turn the HANDSET
RETAINER 180
Figure 2 Handset Retainer for Wall Mounting
