2. Installation
This telephone is designed to plug straight into a modular style socket. If you do
not have one of these sockets, they can be obtained from your Network Supplier.
Connection
Insert the line cord into the socket. Set the ringer volume control, and ringer pitch
adjust as desired.
Wall mounting
Using the template supplied, position the telephone where you want to wall
mount. Drill two holes and fix roundheaded screws, leaving them slightly proud
of the surface. Position the telephone over the screws and slide downwards into
place.
FOR WALL MOUNT
Figure 1 Wall Mounting
