PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE:
Drawingsforillustrationpurposeonly.Actualproductmayvary.Nottoscale.
For Pools with Dual Suction Outlets Configuration:
InordertocomplywiththerequirementoftheVirginiaGrahameBakerAct(forUSAandCanada),your
poolisdesignedwithdualsuctionoutletsandoneinletfittings.Overviewofthedualsuctionoutlets
configuration is as follow:
