SETUP INSTRUCTIONS (continued)
4
6 7
5
Attach one end of the
vacuum hose (13) to the
vacuum body (3). Make
sure the vacuum hose end
is covering the hose seal (2)
on the vacuum body.
Squeeze the spring tips (1) and
attach the telescoping aluminum
shaft (10) onto the vacuum
body (3). Make sure the shaft is
securely attached by checking the
spring “pops” into the pre-drilled
holes. Adjust the length of the
shaft by unlocking, extending and
locking each section accordingly.
Screw the
adaptor
(9) to the
threaded strainer connector,
from inside of the pool.
Inlet hose connection
outlet hose connection
Inside of the
Pool Wall
Threaded Strainer
Connector
Strainer Grid
Inlet hose connection
outlet hose connection
Inside of the
Pool Wall
Threaded Strainer
Connector
Inside of the
Pool Wall
