(333IO) 42” LADDER WITH REMOVABLE STEPS ENGLISH 4.875” X 7.25” PANTONE 295U 03/30/2022
333
A
S AVE THESE INSTRUCTIONS
Page 9
8. AFTER USE OF LADDER
(refer to figure 7):
9. REMOVING THE STEPS FROM THE SECURED POSITION
(refer to figure 8):
a) With your right hand pull and hold the latch towards you, while at the same time with
your left hand press the white protruding buttons and simultaneously lift that leg out of
the cavity exposing the lower white protruding buttons.
b) Allow the leg to rest over the top brace (make sure it does not fall back into the cavity),
and quickly lift up the “removable step assembly” out of its secured position.
c) See step 5 for re-attaching the removable steps.
WINTERIZING / LONG TERM STORAGE
1.
Remove the “removable steps” as shown in the After Use of Ladder section, see figure 7.
2.
Remove the ladder from the pool, and make sure the ladder and the removable steps are
thoroughly dry before long term storage.
3.
Bring the ladder and all its components indoors and store in a safe and dry area, preferably
between 32°F (0°C) and 104°F (40°C).
4.
Be sure the ladder and all components are stored in a safe place away from children’s
reach.
5.
Step disassembly:
7
Press
and
Pull
Press
and
Pull
3
1
2
LADDER SETUP (continued)
8
2
2
3
1
1
1
To Next Page
