PARTS
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE:
Drawings for illustration purpose only. Actual product may vary. Not to scale.
SPA SUCTION FITTING
Self-contained spa fi ttings. – For multiple outlet use only. – Wall mounting only.
Replace suction fi ttings within 3 installed year. – Tool required: screwdriver.
Spa suction fi tting maximum fl ow rate: 8.5 gpm (510 gph)
• Check suction strainer fi tting and fasteners for damage or tampering before each use of the spa.
• For service and winterization instructions refer to “Maintenance” and “Storage” sections.
• Read and follow all instructions, save these instructions for future reference.
