When ordering parts, be sure to quote the model number and part numbers.
PARTS (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
Page 7
REF. NO. DESCRIPTION QTY.
PART NO.
1 CONTROL BASE 1 12328
2 SPA FILTER MOTOR 1 11888
3 CONTROL PANEL (INCLUDED #4) 1 11936
4 CONTROL PANEL BOLT 3 11786
5 PRESSURE GAUGE 1 11741
6 CONTROL PANEL BOLT WRENCH 1 11053
7 SPA INFLATION HOSE 1 11830
8 SPA CONTROL INLET/OUTLET O-RING 2 11788
9 ELECTRIC AIR PUMP 1 11962
10 SPA DRAIN PLUG 1 11696
11 SPA DRAIN VALVE ADAPTOR 1 11718
12 FILTER CARTRIDGE HOUSING 1 11798
13 FILTER CARTRIDGE 2 11692
14 FILTER CARTRIDGE HOUSING LID 1 11797
15 INLET PLUG 1 11739
16 SPA TUB 1 12086
17 SPA COVER 1 11784
18
SPA COVER INFLATABLE BLADDER (PRE-INSTALLED IN SPA COVER)
1 11689
19 GROUND CLOTH 1 11717
20 CHEMICAL DISPENSER 1 11614
21 TEST STRIPS 1 11855
22 WRENCH 1 11742
23 OUTLET PLUG 2 11782
24 INFLATION PUMP ADAPTOR 1 11964
25 MALE BUCKLE 6 11850
26 FEMALE BUCKLE 6 11849
27 MANUAL AIR PUMP 1 11960
