SAVE THESE INSTRUCTIONS
(106GS) MODEL 638G FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2018
English
Page 5
SETUP INSTRUCTIONS
Be sure you have access to water to fill the pool and chemicals for the water.
IMPORTANT: This filter pump is shipped with the air release valve (1) open (open the air
release valve if necessary). DO NOT replace the air release valve until you reach STEP #8.
Failure to follow these instructions will result in air trapped inside filter housing; the motor
will run dry, be noisy and malfunction.
1.
2. Place the filter pump the length of the hose away from the pool wall where the lower black
service and maintenance.
3. (14 & 10) into the upper protruding hose connections, and then attach
the pool inlet air adaptor (16) to the upper protruding fitting. Screw the air jet valve (15) over
the pool inlet air adaptor (16). Then insert the strainer union (9 & 11) into the lower protruding
hose connections. The hoses (8) fit over the strainers inserted into the connections.
4. There are two hoses to be connected to the filter pump hose connections. With hose clamps (7),
fasten one of the hoses (8)
5. (16) and to the lower pump connection.
Make sure all the hose clamps (7) are tight. NOTE: Make sure the air jet valve (15) is securely
tighten onto the pool inlet air adaptor (16) and facing up.
6. (13) from the filter
housing. Grasp and remove the housing cover (3)
(13) back onto the filter
housing.
7.
automatically flow down into the pump.
8. When water starts flowing out of the air release valve hole, screw in the air release valve back
NOTE: Venting the system is necessary for air to escape as the filter housing fills with
water.
9.
cover. Plug the transformer power cord into a properly installed electrical socket.
10.
NOTE:
void the warranty.
WARNING
Risk of electric shock. Connect transformer only to a grounding type receptacle
protected by a ground-fault circuit interrupter (GFCI) or residual current device
(RCD). Contact a qualified electrician if you cannot verify that the receptacle is
protected by a GFCI/RCD. Use a qualified electrician to install the GFCI/RCD,
which has a maximum rate of 30mA. Do not use a portable residual current
device (PRCD).
