There are three mounting holes located at the bottom of the filter pump base. These holes are
the filter pump to be secured to the ground or to a base in a permanent upright position.
with a 7mm width.
The filter pump can be mounted on a cement base or onto a wooden structure to prevent
two possible ways of upright mounting.
SETTING UP FILTER PUMP
FILTER PUMP STATIONARY MOUNTING OPTION
145mm
145mm
145mm
145mm
145mm
145mm
-- (3) x M6 HEXAGON LOCK-NUTS
-- (3) x M6 HEXAGON HEAD BOLTS
