Invacare 6264P - Page 4

Leg Extensions and 4 Part No 1118382
Wheeled Walker Accessories
Installing Rear Leg Extension Options
NOTE:Forthisprocedure,refertoFIGURE 2.
NOTE:RefertoInstallationWarningonpage 2.
1. Pressthesnapbuttonstoremovethetwoexistingrearlegextensionsfromthewalker.
NOTE:Therearlegextensionswillnotbereassembledtothewalkerwhenusingtherearwheel
attachments.
2. Pressthesnapbuttononthewalkerframeandinstallthenewwheelattachment/leg
extensionontorearlegofthewalker.
3. RepeatSTEP2forremainingrearleg.
4. Adjustthewheelattachment/legextensiontooneoftheadjustmentholes.
5. RepeatSTEP4forremainingwheelattachment/legextension.
6. Ensurethatthesnapbuttonofeachlegfullyprotrudesthroughthedesiredadjustment
holeandlegsareadjustedsothewalkersits level.
FIGURE 2 Installing Rear Leg Extension Options
Installing the Glide Tip
NOTE:Forthisprocedure,refertoFIGURE 3onpage5.
NOTE:RefertoInstallationWarning
onpage 2.
1. Pressthesnapbuttonsonthewalkerframetoremovetherearlegextensionfromthe
walker .
2. Firmlygraspthelegextensionandperformoneofthefollowing:
•Removetheexistingglidetipfromthelegextension.
•Removetherubbertipfromthelegextension.
Adjustment
Holes
Adjustment
Holes
DETAIL “A” - MODEL NOS.
6264, 6264P, 6265, AND 6265P
DETAIL “B” - MODEL NOS.
6263 AND 6274
Brake
with
Wheel
Sure Glide
Adjustment
Holes
DETAIL “C” - MODEL NO.
6266
NOTE:Brakewithwheelison
samesideofadjustmentholes
onmodelnos.6264and6265.
