Leg Extensions and 6 Part No 1118382
Wheeled Walker Accessories
Tightening Swivel Casters
NOTE:RefertoInstallationWarningonpage 2.
1. Removeswivelwheelattachmentsfromfrontlegsbydepressingsnapbutton.
2. Holdoneswivelwheelattachmentwiththewheelupasshowninfigure4.
3. Turnhexnutclockwisewithawrenchtotightenswivelcaster.
4. RepeatSTEPS2‐3forremainingswivelwheelattachment.
5. Pressthesnapbuttonsandslidetheswivelwheelattachmentsontothefrontlegsof
thewalker .Ensurethatthesnapbuttonofeachlegfullyprotrudesthroughthedesired
adjustmentholeandlegsareadjustedsothewalkersitslevel.
\
FIGURE 4 Replacing Fixed Wheels/Swivel Casters
Wheel
Swivel Caster
Housing
Hex
Nut
Leg
Tube
Adjustment
Holes
Snap-Button
