Invacare Action 2 NG Range - Default Chapter; Table of Contents

2
3
A. GENERAL GUIDELINES
Page
1. Safety and operating limits
1.1. Reaching an object from the chair 3
1.2. Transferring to other seats 5
1.3. Tilting 6
1.4. Tilting, Kerbs 6
1.5. Stairways 7
1.6. Slopes 7
2. Operating instructions
2.1. Folding and Unfolding the wheelchair 8
2.2. Wheelchair propulsion 9
2.3. Lifting the wheelchair 9
3. Safety inspection and maintenance
3.1. Performance control 10
3.2. General inspection
10
4. Transportation
11
4.1. Test report 11
4.2. Observations
12
4.3. Restraint systems 13
5. Summary of warranty terms 14
5.1. Standard terms 14
5.2. Limitation of liability
14
6. Operating instructions for optimal safety 14
B. DESCRIPTION OF YOUR WHEELCHAIR
Page
1. Presentation
1.1. Introduction 15
1.2. General description 15
2. Adjustments
2.1. Seat elements 16
2.1.1 Seat upholstery 16
2.1.2 Type of backrest 17
2.1.3 Backrest upholstery 18
2.1.4 Footrest supports 18
2.1.5 Armrests 19
2.2. Frame 20
2.2.1 Side frame 20
2.2.2 Folding system 20
2.3. Rear wheel 21
2.3.1 24" wheels 21
2.3.2 Handrims 21
2.3.3 Axles 22
2.4. Castors 22
2.4.1 8" wheels 22
2.4.2 Front fork 22
2.5. Brakes 23
2.5.1 Manual brakes 23
2.6. Options 24
2.6.1 Seating options 24
2.6.2 Propulsion options 24
2.6.3 Safety equipment and options 24
3. Specication and tool's
3.1. Standard wheelchair specifications 26
3.2. Tools for adjustments and regular maintenance (Not supplied) 27
3.3. Dimensions 27
TABLE OF CONTENTS
