SECTION 6—SEAT-TO-FLOOR HEIGHT
NOTE: To obtain the desired front seat to floor height, it will be necessary to perform
one or both of the following:
• Changing the castor size and/or mounting position on the fork, and/or seat angle
Refer to Removing/Installing/Repositioning the Castor Assemblies paragraph.
• Changing the rear height positioning. Refer to Adjusting Rear Wheel Height
paragraph.
CHANGING SEAT-TO-FLOOR HEIGHT
SEAT ANGLE 3°
REAR WHEEL FRONT CASTOR
SEAT HEIGHT
24”
8”
485 mm A
A
510 mm
B
B
B
A
B
A
