Invacare Aquatec R User Manual

Setup
WARNING!
Riskofinjuryanddamage!
–Onlysetupthebathliftinbathtubsthat
complywiththespecicationsofthefollowing
table.
–Ifalateraloverowispresentinthebath
tub,usethespecialsideaps(availableasan
accessory).
A
B
C
H
E
80 mm
A
Tublength,
bottom
≥800mm
B
Tubwidth,
bottom
(inside)
min.280mm
C
Tubwidth,at
80mmheight
(inside)
≥430mm
E
Tubwidth
(outside)
580-690mm(withspecialside
aps)
700-740mm(withstandardside
aps)
750-1000mm(withspecialside
aps)
H
Tubheight
(inside)
≤420mm
(withheightadapter,max.+60
mm)
IMPORTANT!
–Ensurethatthesuctioncupsaremounted.
–Ensurethatthebatteryinthehandcontrolis
charged.
–Ensurethatthespindlefootisfullyinserted.
–Whenliftingbathliftcomponents,remember
tocorrectlyassesstheweights,seesection9.1
Dimensionsandweight,page24.
–Ifahandrailismountedattheinsideofthe
bathtub,usethesideapdiverters(available
asanaccessory).
–Foldthesideapsoutwardsbeforeraisingthe
backrest.
