SECTION 7—JOYSTICK
At’m 34 Part No. 1125035
FIGURE 7.2 Repositioning the Joystick
Mounting
Hole on Arm
Mounting Holes
on Bracket
Quick-Release
Pins
Joystick
Mounting
Bracket
DETAIL “A”
Joystick
Cable
Tie-Wrap
Tie-Wrap
Tie-Wrap under Flap
(Hidden from View)
Basket
Upholstery
Flap
Joystick
